Horex VR6 Black Edition







Make Model

Horex VR6 Black Edition

Year

2016

Engine

Four stroke, V6, 15 degree  V-angle mirrored cylinder offset, triple overhead cam, 3 valves per cylinder

Capacity

1218 cc / 74.32 cu-in
Bore x Stroke 68.2 x 55.4 mm
Compression Ratio 12.5:1
Cooling System Liquid cooled

Induction

Turbo. Rotrex radial compressor C-series, detatchable
 Starting Electric

Max Power

167.7 hp / 122.4 kW @ @ 8500 rpm

Max Torque

138 Nm / 101.5 lb-ft @ 7000 rpm
Clutch Multi-disc oil bath clutch, operated hydraulically. 1:2.47 ratio.fuel capacity: 4.00 litres (1.06 gallons)

Transmission

6 Speed
Final Drive Chain
Frame Aluminum bridge frame with steel steering head

Front Suspension

Öhlins upside-down fork (Ø 43 mm) with adjustable spring preload, compression and rebound damping
Front Wheel Travel 120 mm / 4.7 in

Rear Suspension

Öhlins TTX36 GP suspension struts with adjustable spring base, rebound and compression damping and built-in hydraulic spring preload adjustment
Rear Wheel Travel 120 mm / 4.7 in

Front Brakes

2x 320mm disc. ABS. Radial 4-piston calipers. Bremo.

Rear Brakes

Single 264mm disc. ABS. 2-piston caliper. Bremo
Wheels Alluminium spoke wheels

Front Tyre

120/70-ZR17

Rear Tyre

190/55-ZR17
Rake 24.0°
Trail 95 mm / 3.7 in
Wheelbase 1475 mm / 58.1 in
Seat Height 800 mm / 31.5 in

Dry Weight

216.0 kg / 476.2 lbs

Fuel Capacity

17 Litres / 4.5 USA gal

With the new HOREX VR6 Black Edition the German traditional brand HOREX presents its second model series. Just as with the sister model Silver Edition, this also marks the launch of a new model series (Café Racer), which is also limited to a further 33 specimens.

Similar to the Silver Edition, the Black Edition also defines the technically feasible. The Black Edition, unlike the sister model Silver Edition, is, however, a pure single seater and can therefore be optionally ordered with a maximum sporty cafe-racer-steering configuration.
