Suzuki GS 750E

.

Make Model

Suzuki GS 750E

Year

1978

Engine

Four stroke, transverse four cylinders, DOHC, 2 valve per cylinder.

Capacity

748 cc / 45.6 cu in
Bore x Stroke 65 x 56.4 mm
Cooling System Air cooled
Compression Ratio 8.7:1
Lubrication Wet sump

Induction

4 x Mikuni VM26SS carburators

Ignition

Battery, coil
Battery 12V 14AH/10 hr.
Generator 3 ph AC
Spark plug type NGK B8ES
Starting Electric & kick

Max Power

53.6 kW / 72 hp @ 8500 rpm

Max Torque

60 Nm / 6.1 kgf-m / 44.2 lb-ft @ 8250 rpm
Clutch Wet multi-plate

Transmission

5 Speed
Final Drive Chain, 630SO 96 link, O-ring .81/2 in. free-play
Primary reduction 2.152 (99/46)
Final reduction 2.733 (41/15)
Gear Ratio 1st 2.571 (36/14) / 2nd 1.777 (32/18) / 3rd 1.380(29/21) / 4th 1.125 (27/24) / 5th 0.961 (25/26)

Front Suspension

35mm Kayaba with anti dive adjustable air pressure.

Rear Suspension

Dual shocks adjustable preload and spring rebound damping.

Front Brakes

Single 292 mm disc, 1 piston caliper

Rear Brakes

Single 292 mm disc ,1 piston caliper

Front Tyre

3.25 H19

Rear Tyre

4.00 H18
Steering Angle 40°
Caster 63°
Trail 107 mm / 4.21 in
Turning radius 2.5 m / 8.5 ft
Dimensions Length  2225 mm / 87.6 in
Width      870 mm / 34.3 in
Height   1170 mm / 46.1in
Wheelbase 1490 mm / 58.7 in
Ground clearance 150 mm / 5.9 in

Dry Weight

223 kg / 492 lbs.

Fuel Capacity

18 Litres / 4.8 US gal / 4.0 Imp gal
Reserve 2 Litres / 0.5 US gal / 0.44 Imp gal

Consumption Average

6.4 L/100 km / 15.6 km/l / 36.7 US mpg / 44.1 Imp mpg

Standing ¼ Mile

12.8 sec

Top Speed

180 km/h / 112 mph
.
