Suzuki GSX 1100LT

.

Make Model

Suzuki GS 1100LT

Year

1980-81

Engine

Four stroke, transverse four cylinder, DOHC, 4 valves per cylinder.

Capacity

1074 cc / 65.5 cu-in
Bore x Stroke 72 x 66 mm
Cooling System Air cooled
Compression Ratio 9.5:1
Lubrication Wet sump, trochoidal pump

Induction

4x 34mm Mikuni  BSS4SS

Ignition

Transistorized pointless
Battery 12V, 14AH
Starting Starting

Max Power

72.9 kW / 100 hp @ 8700 rpm

Max Torque

85.3 Nm / 8.7 kgf-m / 62.9 ft-lb @ 11200 rpm
Clutch Wet. 18 plates

Transmission

5 Speed

Final Drive Chain

Front Suspension

Telehydraulic forks

Rear Suspension

Swinging arm forks with adjustable shock absorbers.

Front Brakes

2x 295mm discs

Rear Brakes

Single 295mm disc

Front Tyre

100/90-19

Rear Tyre

130/90-16
Dimensions Length 2300 mm / 90.6 in
Width 905 mm / 35.6 in
Height 1260 mm / 49.6 in
Wheelbase 1525 mm / 60.0 in

Wet Weight

259 kg / 571 lbs

Fuel Capacity

15 Litres / 3.4 gal
