Suzuki GV 1400LX Cavalcade

.

Make Model

Suzuki GV 1400 Cavalcade LX

Year

1985 - 88

Engine

Four stroke, 82°V-Four, DOHC, 4 valves per cylinder, TSCC.

Capacity

1360 cc / 83 cu in
Bore x Stroke 81 x 66 mm
Compression Ratio 9.5:1
Cooling System Liquid cooled

Induction

4 x 33mm Mikuni BDS33SS carburetors

Ignition

CDI

Starting

Electric

Battery

12V, 20Ah

Max Power

81.6 kW / 112 hp @ 7000 rpm

Max Torque

124 Nm / 12.6 kgf-m / 91.5 lb-ft @ 5500 rpm

Clutch

Wet, multi-plate

Transmission

5 Speed

Final Drive

Shaft

Primary Drive

72/41 (1.76)

Final Drive

32/12 (2.6)

Gear Ratios

1st 33/12 (2.75) / 2nd 32/19 (1.68) / 3rd 25/20 (1.25) / 4th 25/25 (1.00) / 5th 23/27 (0.85)

Front Suspension

Telescopic, coil-spring, oil-damped, center-axle fork, 41mm tubes

Front Wheel Travel

150 mm / 5.9 in

Rear Suspension

Swing Arm, pneumatic/coil spring, oil damped, air adjustable shock absorbers, Suzuki "Auto-Leveling" System

Rear Wheel Travel

106 mm / 4.2 in

Front Brakes

2 x 310mm Discs, 2 piston calipers

Rear Brakes

Single disc, 1 piston caliper

Front Tyre

130/90-16 67H

Rear Tyre

150/90-15 74H

Rake

29.0o

Trail

119 mm / 4.7 in

Dimensions

Length: 2530 mm / 99.6 in
Width:     935 mm / 36.8 in
Height:  1550 mm / 61.0 in

Wheelbase

1670 mm / 65.7 in

Ground Clearance

130 mm / 5.1 in

Seat Height

780 mm / 30.8 in

Turning Circle

3.3 m / 10.8 ft

Dry Weight

349 kg / 768 lbs

GVWR

590kg / 1300 lbs

Fuel Capacity

23 Litres / 6.1 US gal / 5.1 Imp gal

Oil Capacity

3.2 Litres / 3.4 US qt / 2.8 Imp qt

Fuel Consumption Average

6.2 L/100 km / 16.2 km/l / 38 US mpg / 45.6 Imp mpg

Standing 1/4 Mile

12.8 sec / 163 km/h / 101 mph
.
