Suzuki GW 400 Inazuma

.

Make Model

Suzuki GW 400 Inazuma

Year

1997 - 02

Engine

Four stroke, transverse four cylinders

Capacity

399 cc / 24.3 ci un
Bore x Stroke 52 x 47 mm
Compression Ratio 11.2:1
Cooling System Air/oil cooled

Induction

Carburetor CVR28

Ignition

Full transistor

Starting

Electric

Max Power

37.9 kW / 52 hp @ 11000 rpm

Max Torque

36 Nm / 3.7 kgf-m / 26.6 lb-ft @ 9500 rpm

Transmission

6 Speed, constant mesh

Clutch

Wet, multi-plate

Final Drive

Chain

Primary Reduction

1.785

Final Reduction

3.500

Gear Ratios

1st 3.250 / 2nd 2.266 / 3rd 1.705 / 4th 1.400 / 5th 1.277 / 6th 1.136

Frame

Double cradle

Rake

25o

Trail

102 mm / 4.2 in

Front Suspension

Telescopic fork

Rear Suspension

Swingarm, twin shocks, springs

Front Brakes

2 x 290 mm Dics, 4 piston caliper

Rear Brakes

Single disc, 1 piston caliper

Front Tyre

120/70-17

Rear Tyre

170/60-17

Dimensions

Length: 2140 mm / 84.3 in
Width:     745 mm / 29.3 in
Height:  1090 mm / 42.9 in

Wheelbase

1460 mm / 57.5 in

Ground Clearance

125 mm / 4.9 in

Seat Height

760 mm / 29.9 in

Seat Height

760 mm / 29.9 in

Minimum Turning Radius

2.7 m / 8.9 ft

Fuel Capacity

18 Litres / 4.8 US gal / 4.0 Imp gal
