Yamaha ST 225 Bronco

.

Make Model

Yamaha ST 225 Bronco

Year

1997 -

Engine

Four stroke, single cylinder, SOHC

Capacity

223 cc / 13.6 cu-in
Bore x Stroke 70 X 58mm
Cooling System Air cooled
Compression Ratio 9.5:1

Induction

34mm Mikuni BST34 carburetor

Ignition

CDI
Starting Kick

Max Power

20 hp / 14.9 kW @ 8000 rpm

Max Torque

1.9 kgf-m / 13.7 lb-ft @ 7000 rpm

Transmission

6 Speed
Final Drive Chain

Front Suspension

Telescopic fork: 226mm wheel travel

Rear Suspension

Swingarm rebound adjustable. single shock, 145mm.wheel travel

Front Brakes

Single 220mm disc

Rear Brakes

Single 110mm drum

Front Tyre

2.75-19

Rear Tyre

120/80-18
Dimensions Length 2030 mm / 79.9 in
Width 800 mm / 31.4 in
Height 1140 mm / 44.8 in
Seat Height 795 mm / 31.2 in

Dry Weight

123 kg / 271 lbs

Fuel Capacity

8.3 Litres / 2.2 US gal

This scrambler model was designed with a good amount of the retro styling that was popular in the Japanese motorcycle industry at the time. Taking the frame and engine of the SEROW225 as its base, the fuel tank, headlight, instruments, front and rear fenders and other parts were made of chromed metal for a look of quality and a design similar to the rounded image of the 1968 DT-1 model. Its appeal included its easy-to-use performance and ride that made it well adapted to a wide range of on-road and off-road uses, and attractive exterior styling.
