Yamaha FJR 1300E /ES







Make Model

Yamaha FJR 1300E / ES

Year

2014

Engine

Four stroke, transverse four cylinder, DOHC, 4 valves per cylinder.

Capacity

1298 cc / 79.2 cu-in cc / 79.2 cu-in
Bore x Stroke 79 x 66.2 mm
Compression Ratio 10.8:1
Cooling System Liquid cooled
Lubrication Wet sump

Induction

Electronic Fuel Injection

Ignition

TCI: Transistor Controlled Ignition
Starting Electric

Max Power

145 hp / 105.7 kW @ 8500 rpm

Max Torque

125 Nm / 13.7kgf-m @ 6000 rpm
Clutch Wet, multiple discs, cable operated

Transmission

5 Speed
Final Drive Shaft
Frame Aluminium, twin spar

Front Suspension

48mm upside-down telescopic fork w/adjustable preload, compression and rebound damping;
Front Wheel Travel 137 mm / 5.3 in

Rear Suspension

Single shock, link-type, w/adjustable preload and rebound damping;
Rear Wheel Travel 129 mm / 4.9 in

Front Brakes

2x 320mm discs 4 piston calipers

Rear Brakes

Single 283mm disc  2 piston caliper

Front Tyre

120/70 ZR17

Rear Tyre

180/55 ZR17
Dimensions

Length 2230 mm /  87.8 in.

Width  749.3 mm / 29.5 in.

Height 1455 mm / 57.3 in.

Wheelbase 1544.3 mm / 60.8 in
Ground Clearance 130 mm  /  5.1 in.
Rake 26.0°
Trail 109 mm  / 4.3 in.
Seat Height 805 mm - 825.5 mm  /  31.7 in - 32.5 in.

Dry Weight

264 kg / 582 lbs
Wet Weight 292 kg / 644 lbs

Fuel Capacity

25 Liters / 6.6 gal

The highly advanced FJR1300AS is like nothing else. And what sets it apart is its electronic clutchless gear shift system that allows you to change gear with your left foot or thumb without using the clutch lever. Which means less effort and more enjoyment on every ride.

This sophisticated long-distance motorcycle is also equipped with the latest electronically-adjustable suspension system featuring upside down forks - allowing you to modify your preload and damping settings at the flick of a switch.

With its mighty 1,298cc engine and sporty aluminium chassis, as well as cruise control and traction control systems, the FJR1300AS is ready to change your view of the world

There Are No Limits

Once you get moving on your FJR1300AS, there's virtually no limit to where you can go. With its outstanding 1,298cc inline 4-cylinder engine and aluminium chassis, this sport tourer is built to carry you and your passenger across huge distances.

Yamaha's advanced YCC-S clutchless shifting system means you use less mental and physical energy when riding, so you'll arrive feeling more relaxed. The latest electronically-adjustable suspension system featuring new upside-down forks allows you to instantly fine tune your bike to suit the conditions.

And our easy-to-use cruise control system allows you to maintain a constant speed in hilly terrain.

   Key Features

YCC-S clutchless gear shifting system

Smooth 1,298cc inline 4-cylinder engine with YCC-T

Electronically-adjustable suspension system

Sportsbike-type aluminium frame for agile handling

Upside-down front forks

Fully-adjustable screen, cowl, seat and handlebarsYamaha D-MODE for softer or hardcore power

Easy-to-operate cruise control system

Switchable Traction Control System (TCS)

Large 25-litre fuel tank for extended riding range

Sidecases, heated grips and 12v socket as standard

Clean and quiet-running shaft drive system

Features and Benefits

Clutchless gear shifting

What sets the FJR1300AS apart is its unique Yamaha Chip Controlled Shift system (YCC-S), which allows you to change gear with your left foot or thumb without ever touching the clutch lever. As well as being quick and easy, this system makes for reduced fatigue on long trips. And a new 'Stop Mode' automatically downshifts to 1st gear when you stop.

High-performance 1,298cc inline 4-cylinder engine

Featuring a Yamaha Chip Controlled Throttle (YCC-T) for smooth power delivery, the advanced inline 4-cylinder powerplant delivers outstanding sports performance. Its high torque output makes for strong acceleration in all gears - and the impressive top end enables you to cover massive distances without trying too hard.

Fully adjustable ergonomics for added comfort For maximum riding pleasure the FJR1300AS is designed to allow easy adjustments to the riding position and aerodynamics. The seat height and handlebar position can be fine-tuned to suit different riding styles - and for effective wind protection there's an electrically adjustable screen and an air management system.

Advanced electronic control systems

The latest-generation FJR1300AS benefits from the use of many advanced electronic control systems, including traction control (TCS), and cruise control.

Yamaha's D-mode system allows you to adjjust engine performance to suit relaxed or sports riding - and the electronically-adjustable suspension makes for quick and easy chassis tuning.

Upside down front forks

The latest FJR1300AS is equipped with newly designed upside-down front forks which form an integral part of the new electronically adjustable suspension package. Together with the rear shock, the advanced new forks can be electronically adjusted to suit different load and riding conditions, allowing the rider to fine tune the system in seconds.

Sophisticated 3-part instrumentation

To complement its sophisticated sport tourer specification, the latest FJR1300AS is now equipped with a high-specification 3-part instrument panel. This hightech automobile-style console includes an analogue tachometer on the left, central digital speedometer and a multi function dot matrix display on the right.

.
