Big Bear Choppers Venom Two-up

.

Make Model.

Big Bear Choppers Venom Two-up

Year

2015

Engine

Four stroke, V-twin

Capacity

1819 cc / 111 cu in
Bore x Stroke 104.8 x 104.8 mm / 4 ⅛ x 4⅛ in
Cooling System Air cooled
Exhaust BBC Chrome Baffled Radius Design

Induction

S&S Super E Carburetor or BBC-S&S V111™ EFI Evolution

Ignition

S&S
Battery Extreme Magna Power AGM, 40A
Starting Electric

Max Power

86.4 kW / 115.8 hp

Max Torque

166.3 Nm / 16.95 kgf-m / 122.8 lb-ft

Transmission

Baker, 6-speed overdrive
Final Drive RSD belt
Frame BBC Sled Chopper, softail, 0.160" wall DOM seamless frame tube, thick 0.160" wall, 3" under stock downtube, thick 0.250" wall 3" stretch backbone

Front Suspension

BBC Smooth Mount Hidden Axle
Front Wheel Travel 76 mm / 3.0 in

Rear Suspension

Progressive suspension
Rear Wheel Travel 95.3 mm / 3.75 in

Front Brakes

Disc, P.M. 4-Piston Caliper

Rear Brakes

Disc, BBC-P.M. 4-Piston Caliper
Wheels RC Components, forged aluminium, polished
Front Rim 2.125 x 21 in
Rear Rim 8.50 x 18 in

Front Tyre

Avon Cobra 90 mm

Rear Tyre

Avon Cobra 250 mm
Rake 40°
Trail 95.3 mm / 3.75 in
Dimensions Length: 2743 mm / 108 in
Wheelbase 2032 mm / 80 in
Seat Height 584 mm / 23 in

Dry Weight

318 kg / 700 lbs

Fuel Capacity

Carburetor model: 13.2 L / 3.50 US gal

EFI model: 13.7 L / 3.625 US gal

Source

Big Bear Choppers



Are you looking for an American made motorcycle that looks cool, handles great, has lots of chrome and the opportunity to bring a passenger with you on your rides? We think we got it. We took our famous single rider Venom ProStreet and designed it to be fun for both of you. With the help of a strutted type rear fender, built-in passenger seat with a back rest, this version of our Venom is sure to please the people.


Engine

Reliability, power and comfort... the best of all worlds. And when we say reliability, we not only mean the life of the engine, but the life of motorcycle and everything that's bolted to it. Branded as V111™,' this internally reformed 111 cubic inch engine boasts a healthy 122.8 lbs. of torque at the crank. With a configuration of a 4 1/8” bore and 4 1/8” stroke, proprietary compression ratios, redesigned cam timing, and reciprocating weights all result in an incredibly smooth running engine while meeting all the strict legal requirements. While looking like any other S&S Super Sidewinder engine from the outside, the essence of this new engine is the low vibration. High engine vibration is an enemy to both the rider and the motorcycle. The effects of high engine vibration may cause premature rider fatigue as well. Eliminate engine vibration and you will eliminate potential problems.



Between the EFI and the carbureted V111™, there isn’t going to be much of a difference in performance, provided you maintain constant ambient conditions (humidity, temperature, elevation, etc.). This is where the beauty of the closed-loop EFI system comes into play. The system is continuously monitoring the engine, and tuning itself to optimize performance for that given scenario or environment. So, while you might not be able to notice power difference between the EFI and a carbureted engine, once you take that bike up the mountain, or get a day that’s significantly hotter than the day it was tuned, that EFI engine will easily outperform the carbureted engine (unless you want to take a supply of different jets with you on the ride).



Transmission and Drivetrain

This is the original 6-speed design that revolutionized the American V-Twin industry. Yet, it's still the best overdrive 6-speed built to this day ...hands down. This Detroit built tranny is designed and manufactured to comfortably handle the power from our engines while looking good behind it.



Keeping with the mindset of making form and function coexisting, this newly designed proprietary primary is built tough and reliable along with a very sleek, new generation styled aesthetics with a cool BBC branded inspection cover. This primary drive is approximately 200% stronger than most other manufacturer’s primaries with its machined forged aluminum inner and outer cases. The dense aluminum material makes for a unit that does not flex under heavy torque, and absorbs most engine vibration. Another great attribute that sets this primary drive ahead of the curve is the triple seal design on the main shaft, as opposed to an industry standard single seal, insuring virtually no leaks. The starter motor shaft accessory plate is removable for an easy starter change-out. The internals utilize an easy-to-replace standard type clutch basket and a compensating sprocket for a smooth power transfer.



Electrical

We teamed up with Wire-Plus, the industry's leader in motorcycle electronics, to design a wiring harness with no compromises. Combine this harness with the high-end brand name electrical components like the Spyke charging system and the Crane ignition, and we're sure your seat time will be long. You won't be on the side of the road kicking rocks.



Frame and Body

The Venom Series motorcycles was launched in 2002 and set a higher standard with it's pioneered frame design in the industry with it's large single radius downtube and the famous Venom swingarm. The Venom Chopper frame is the big brother to the Venom ProStreet frame with it's 6" of downtube stretch.

The frame is the foundation of the motorcycle's aesthetics and reliability. All our frames are designed and manufactured in house in our San Bernardino facility. Every frame component (e.g. neck, side plates, tank mounts, tranny plate, axle adjusters, etc) are CNC manufactured with precision. Utilizing a 0.250 wall, 1.5” tube steel for the backbone and 0.160 wall, 1.125” tube for the rest of the frame, BBC uses the best steel possible for our frames. All frames are 100% TIG welded for a clean, strong and precise fusion. We think we make a statement about our confidence with a lifetime warranty on the frames we make.

Like our frames, our tanks and fenders are designed and manufactured in-house. We produce the sheetmetal with the frame as a unit, then gets 'mock-up' before we hand it over to our painters or ship it out to the unassembled kit customers. We use heavy duty 12 gauge steel for our fenders and 14 gauge steel for the tanks. All tanks are pressure tested and the fenders are computer cut. We guarantee and warranty any leaks from the tanks and cracks in the fenders for your lifetime.

Suspension

Designed and manufactured in-house, our fully chrome frontend is exclusively made for our motorcycles to be aesthetically cool and functionally bomb proof. The BBC logo branded 6° triple trees have what we call a 'smooth mount' design - you don't see the tube and axle nuts on top. And what we mean with the 'hidden axle' - it's a nutless type axle, making the finish smooth. With all our calculations with the frame and frontend, we've landed the front wheel in the sweet spot of the final trail measurement. This allows for a motorcycle with no frontend flop and high speed wobble. And at the back, there's no better American Made shock to use than the industry's premier shock absorber, Progressive Suspension. The chrome pair of oil dampened shocks produce a good ride, which is just one more reason why our motorcycles out handle and beat the comfort of the other guys bikes.
