Honda CB 300F

.

Make Model

Honda CB 300F

Year

2017 - 18

Engine

Four stroke, single cylinder, DOHC, 4 valve per cylinder

Capacity

286 cc / 17.45 cub in.
Bore x Stroke 76  x 63 mm
Cooling System Liquid cooled
Compression Ratio 10.7: 1

Induction

PGM-FI electronic fuel injection

Ignition

Computer-controlled digital transistor with electronic advance
Starting Electric
Max Power 29.5 hp / 21.5 kW @ 8500 rpm
Max Torque 27 Nm / 19.9 lb-ft @ 7250 rpm
Clutch Wet multiplate hydraulic clutch

Transmission

6 Speed
Final Drive #520 O-ring-sealed chain
Max Power 22.7 kW / 30.4 hp @ 8 500 rpm
Max Torque 27 Nm / 2.75 kgf-m / 19.9 bl/ft @ 7 250 rpm
Frame Diamond; steel twin-spar

Front Suspension

37 mm telescopic fork
Front Wheel Travel 120 mm / 4.7 in
Rear Suspension Monoshock damper, Pro-Link swingarm, 5 position preload adjustability
Rear Wheel Travel 103 mm / 4.07 in
Front Brakes Single 296 mm disc 2 piston caliper, ABS
Rear Brakes Single 220 mm disc 1 piston caliper
Rims Multi-spoke cast aluminium;
Front Wheel MT2.75 x 17M/C
Rear Wheel MT4.00 x 17M/C

Front Tyre

110/70-17 radial

Rear Tyre

140/70-17 radial
Rake 25.3°
Trail 98 mm / 3.9 in
Dimensions Length 2035 mm / 82.0 in
Width    720 mm / 28.3 in
Height 1120 mm / 44.0 in
Wheelbase 1380 mm / 54.3
Seat Height 780 mm / 30.7 in
Ground Clearance 145 mm / 5.7 in

Wet Weight

158 kg / 348 lbs

Fuel Capacity

13 Litres / 3.4 US gal

Consumption Average

3.3 L/100 km / 30.2 km/l / 71 US mpg
Instruments Analogue tachometer, digital odometer, speedometer, fuel gauge, temperature gauge and clock.
.

This lightweight and nimble-handling naked bike offers plenty of fun for beginners and experienced motorcyclists. Featuring a 300-class engine, the CB300F carries a dash of attitude and independence along with its versatile creds. Whether for commuting, zipping around town or headed out for a weekend ride, its roomy ergonomics, great handling and broad powerband make every ride a blast. Thanks to its affordable price tag, adding on a few Honda Genuine Accessories is easy—a simple way to give it that extra bit of flair and make it unique.

Craving the purest riding experience around? Look no further

Lots of riders believe less is more, and that’s why so many like this bike. The CB300F was designed to be lighter, smaller and simpler, but it’s still loaded with features. And with its user-friendly size, it’s a great choice for the city and makes an ideal first bike.

Like our CBR300R, the CB300F uses a totally up-to-date single-cylinder engine. The fuel injection system and electric start make it convenient, but the best feature of all may be its combination of enthusiastic power delivery along with awesome fuel efficiency. Practical meets performance—it’s not an either/or proposition with the CB300F—you get to have your cake and eat it too.

Low and Nimble

The CB300F’s narrowness helps make it one of the most maneuverable bikes around. This is all thanks to its single-cylinder engine, low 30.7-inch seat height and light 348-pound curb weight. What you get is a bike that’s easy to put your feet down at a stoplight and a blast to ride the moment it turns green.

Singular Accomplishment

The crowning achievement of the CB300F is its single-cylinder engine with fuel injection, double-overhead cams and a counterbalancer. What you get is the kind of torque and midrange power that’s well suited for all levels of riders.

Ride More. Fill Up Less

The CB300F rocks when it comes time to fill up. With a fuel economy estimate of 78 MPG*, you’re more likely to be laughing at high gas prices. Plus, the CB300F can carry a passenger and is freeway capable. Get all the versatility you need.

Options

The CB300F offers an excellent balance of beginner-friendly features, while experienced riders will appreciate Honda’s famous engineering refinement. Everyone will like the CB300F’s light weight, superb handling, broad powerband and unmatched build quality. Best of all, the CB300F is available in two versions: the CB300F and the CB300F ABS with our Anti-lock Braking System.

Features & Options

286cc liquid-cooled single-cylinder engine
Low seat height
Programmed Fuel Injection
Analog/Digital Instrumentation

Features

286cc liquid-cooled single-cylinder engine
Low seat height
Programmed Fuel Injection
Analog/Digital Instrumentation
Anti-Lock Braking System

The right amount of performance

The 286 cc single-cylinder engine boasts high-performance features such as dual overhead camshafts driven by a Hy-Vo-type silent chain, forked roller rocker arms, a compact four-valve cylinder head, a counterbalance shaft, and liquid cooling.

Light & nimble

Light & nimble The light and compact engine contributes to the CB300FA’s nimble steering, intuitive handling and impressive power-to-weight ratio, allowing it to compete with twin-cylinder bikes of similar displacement.

Easy maintenance

Shim-style valve adjustment allows easy inspection and maintenance, although with extended inspection intervals you’ll ride a long, long time between adjustments.

Compact engine design

The engine countershaft sits lower than the mainshaft in a “stacked” formation to reduce the engine’s front-to-rear dimensions.

Frugal on fuel

The engine produces a remarkably broad torque curve for strong low-rpm performance, the wide spread of power makes the CB300FA easy and confidence-inspiring to ride, in both stop-and-go situations and on the highway, while also returning impressive fuel economy.

Efficient engine

The crankshaft runs in plain bearings for quieter operation and the big end of the connecting rod spins in a needle bearing, both contributing to the engine’s high-performance credentials.

Less vibration – more comfort

A gear-driven counterbalance shaft helps quell engine vibration for enhanced rider comfort. It’s located so close to the crankshaft that the balancer weight passes between the two crank weights to keep the engine as compact as possible while improving mass centralization.

Crisp throttle response

Honda’s Programmed Fuel Injection (PGM-FI) continuously monitors several variables to ensure the correct fuel mixture for the current riding and atmospheric conditions. The system delivers optimal performance and remarkably crisp throttle response over a wide range of operating conditions, plus improved fuel economy.

Broad power delivery

The six-speed transmission works in concert with the engine’s broad power delivery to produce quick acceleration and excellent fuel economy around town. Taller final drive gearing further improves fuel efficiency during highway cruising.

Impressive handling & comfort

Diamond-shaped twin-spar steel frame plus a 37 mm front fork and Pro-Link single-shock rear suspension provide impressive handling and a comfortable ride.

Available Anti-lock braking system

The CB300FA’s ABS (Anti-lock Braking System) provides sure control even on difficult road surfaces.

Outstanding manoeuvrability

Curb weight of only 157.8 kg gives the CB300FA outstanding manoeuvrability and helps instill rider confidence.

Upright seating = Clear view & control

Upright seating position provides a clearer view of the road ahead and helps enhance control.

Grip & handling of a bigger bike

Full-sized 17-inch cast wheels with a 110/70 – 17 front tire and a 140/70 – 17 rear tire provide big-bike feel, grip and handling traits.

Lightweight & attractive

Minimal bodywork with clean, open, sporty styling is not only attractive it makes the CB300FA even lighter.

Information at a glance

Multi-function digital instrument panel includes speedometer, tachometer, engine temperature display, fuel gauge, clock, odometer and trip meter.

Plant your feet with ease

A narrow, low-mounted seat makes it easier to reach the ground.

Double-up with confidence

Grab rails on the tail section are designed to fit gloved hands, giving passengers a dedicated handhold while riding two-up.

Convenient under-seat stowing

Handy under-seat storage area is lockable to help keep small valuables safe.
