Honda CB 750C Custom

.

Make Model

Honda CB 750 Custom

Year

1981 - 82

Engine

Four stroke, transverse four cylinder, DOHC, 4 valve per cylinder

Capacity

748 cc / 45.6 cu-in
Bore x Stroke 62 x 62 mm
Cooling System Air cooled
Compression Ratio 9.1:1

Induction

4x 30mm Keihin carbs.

Ignition

CDI
Starting Electric

Max Power

77 hp / 56.2 kW @ 9000 rpm

Max Torque

67 Nm / 49.4 lb-ft @ 7000 rpm

Transmission

5 Speed
Final Drive Chain

Front Suspension

Adjustable telehydraulic fork.

Rear Suspension

Swinging arm fork with adjustable shocks absorbers

Front Brakes

2x 276mm discs 1 piston calipers

Rear Brakes

190mm Drum

Front Tyre

110/90-19

Rear Tyre

130/90-16

Dry Weight

253 kg / 557.8 lbs

Fuel Capacity

16.2 Litres / 4.2 US gal

Consumption Average

42.9 mp/g

Standing ¼ Mile

12.7 sec / 166.1 km/h

Top Speed

204.7 km/h / 127 mph
.
