Honda CBR 600RR SE

.

Make Model

Honda CBR 600RR Special Edition

Year

2008

Engine

Four stroke, transverse four cylinder, DOHC, 4 valve per cylinder.

Capacity

599 cc / 36.5 cu-in
Bore x Stroke 67 x 42.5 mm
Compression Ratio 12.2:1
Cooling System Liquid cooled
Lubrication Wet sump
Engine Oil Synthetic, 10W/40

Induction

Dual Stage Fuel Injection (DSFI) with 40mm throttle bodies, Denso 12-hole injectors

Ignition

Computer-controlled digital transistorized with
electronic advance and independent four-cylinder 3D-mapped computer control.
Spark Plug NGK, IMR9C-9H
Starting Electric

Max Power

118 hp / 88.1 kW @ 13500 rpm

Max Torque

66 Nm / 48.6 lb-ft @ 11250 rpm
Clutch Cable-operated multiplate wet clutch.

Transmission

Close-ratio 6 Speed
Final Drive  #525 O-ring chain
Frame Aluminium, twin spar

Front Suspension

41mm inverted Big Piston Fork with spring preload, rebound and compression damping adjustability
Front Wheel Travel 120 mm / 4.3 in

Rear Suspension

Unit Pro-Link HMAS single shock with spring preload, rebound and compression damping adjustability;
Rear Wheel Travel 129.5 mm / 5.1 in

Front Brakes

2x 310mm discs 4 piston calipers

Rear Brakes

Single 220mm disc 1 piston caliper

Front Tyre

120/70 ZR17

Rear Tyre

180/55 ZR17
Rake 23.5°
Trail 97.7mm /  3.9 in
Dimensions

Length 2015 mm / 79.3 in

Width   685 mm / 26.9 in

Height 1105 mm / 43.5 in

Seat Height 820 mm / 32.3 in
Wheelbase 1369 mm / 53.9 in
Ground clearance: 135 mm / 5.3 in

Dry Weight

156.5 kg / 345 lbs
Wet Weight 186 kg / 410 lbs

Fuel Capacity

18.2 liters / 4.8 gal

Standing ¼ Mile

11.1 sec

Top Speed

255.3 km/h / 158.6 mph
.

A lighter crank and lighter con-rods means lighter — and smaller — everything else, so the entire package — capped off with 11-ounce lighter magnesium valve covers — measures up as 27.5mm shorter than the 2006, all the while making more power and torque and weighing in at 3.7 pounds less.

“The clutch is lighter, smaller and stronger, and the transmission gets closer ratios and a redesign to reduce driveline lash.”

Engine improvements don’t stop there. We didn’t complain about last year’s clutch or transmission, but Honda improved them anyway. The clutch is lighter, smaller and stronger, and the transmission gets closer ratios and a redesign to reduce driveline lash. There’s also a new gadget called the Intake Air Control Valve (IACV), which smoothes throttle response, avoiding the jerky fuel injection-induced response some other motorcycles are cursed with.

The airbox — which now sucks air through a hole in the front of the frame like the RC-51 — gains seven percent of additional capacity, and the radiator is 40mm narrower, but 34.2mm taller so not too much frontal area is lost. The exhaust now has titanium baffles; they could have put that bling-bling on display like some OEMs do, but they put it inside where it would do the most good.

Suspension and brakes are standard, if effective, fare. In front, a fully-adjustable (except for high-speed settings) 41mm inverted fork and four-piston radial-mount calipers get the job done, (although Toland said the new braking components offer more sensitivity) and in the rear the Honda Unit Pro-Link is bolted to the three-way-adjustable shock. The Unit Pro Link shock linkage is GP-tech for the street; it isolates the suspension almost totally from the frame to ensure the smoothest possible ride.

A Honda Electronic Steering Damper (HESD) that’s half the size (and 20 percent lighter) of last year’s damper keeps the compact chassis — with a steeper rake than the old machine’s — under control by adjusting damping force according to speed.

To wrap up the package, the Honda stylists added a thicker seat (although it’s roadcourse as a DOT race tire on dry pavement would be. I say “probably” because I didn’t want to be that guy who pushed it too hard in the rain and crunched a brand-new bike: I was happy at an 8/10ths pace.

The increased traction meant I could settle down and really get a feel for the machine’s suspension, braking and other qualities. With a team of Honda technicians on hand to ensure a perfect set-up, the suspension felt spot-on, even though they misunderestimated my weight by 20 pounds. Although the track is very smooth, there are some pavement ripples in one high-speed braking zone (thanks, Grand Am cars!) that translated into some choppiness, but I imagine any motorcycle would get bounced around there.Accelerating off of Turn Six down the back straight, the front end gets light but the HESD damper works fine and there’s no drama.

Serious sportbike pilots have eagerly anticipated the arrival of the potent new 2007 CBR600RR, and now the industry experts have confirmed this incredible machine was well worth the wait. Cycle News crowned this middleweight missile winner of its ‘07 600cc Class Shootout, with the more compact, more powerful and lighter-weight 600RR easily besting the competition on both track and street. Roadracing World went one better, calling the CBR600RR “the best 600cc sportbike ever.” Praise doesn’t come much higher. And neither does performance.
