Honda XL 185S

.

Make Model

Honda XL 185S

Year

1981 - 83

Engine

Four stroke, single cylinder, OHC, 2 valve

Capacity

180 cc / 10.9 cu-in
Bore x Stroke 63.0 x 57.8 mm
Cooling System Air cooled
Compression Ratio 9.2:1
Lubrication Wet sump

Induction

Single 24mm Keihin carburetor

Ignition

CDI
Starting Kick

Max Power

16 hp / 11.7 kW @ 8000 rpm

Max Torque

13.6 Nm / 10.0 lb-ft @ 6500 rpm

Transmission

5 Speed
Final Drive Chain
Frame Semi double cradle

Front Suspension

38mm Showa air assisted forks
Front Wheel Travel 200 mm / 7.8 om

Rear Suspension

Showa Pro-Link shocks
Rear Wheel Travel 165 mm /7.2 in

Front Brakes

110mm Drum

Rear Brakes

110mm Drum

Front Tyre

2.75-21

Rear Tyre

4.10-18

Dry Weight

110 kg / 242.5 lbs

Fuel Capacity

7 Litres / 1.8 US gal

Consumption Average

20.3 km/lit

Standing ¼ Mile

17.5 sec

Top Speed

138 km/h / 85.7 mph
