Honda XLV 750

.

Make Model

Honda XLV 750

Year

1984

Engine

Four stoke, 45°V-four cylinders,  SOHC. 3 valves per cylinder

Capacity

749 cc / 45.7 cu-in
Bore x Stroke 79.5 x 75.5 mm
Cooling System Air/oil cooled
Compression Ratio 8.4:1
Lubrication Wet sump

Induction

2x Keihin VD Throttle bore 36 mm

Ignition

CDI
Starting Electric

Max Power

61 hp / 45 kW @ 7000 rpm

Max Torque

7 kgf-m / 68.4 Nm @  5500 rpm

Transmission

5 Speed
Final Drive Shaft
Gear Ratio 1st 2.500:1 (40116) 2nd 1.750:1 (35120)  3rd 1.291:1 (31124)  4th  1.000:1 (28128)  5th 0.833:1 (25130
Clutch Wet, multi-plate
Frame Double cradle

Front Suspension

Telescopic forks
Front Wheel Travel 200 mm / 7.8 in

Rear Suspension

Air assisted Pro-Link
Rear Wheel Travel 180 mm / 7.0 in

Front Brakes

Single 276mm disc 2 piston caliper

Rear Brakes

Drum

Front Tyre

90/90 21

Rear Tyre

130/80 17
Wheelbase 1480 mm / 58.2 in
Seat Height 855 mm  / 33.6 in

Dry Weight

195 kg / 430 lbs
Wet-Weight 212 kg / 467 lbs

Fuel Capacity

19.5 Litres / 5.1 US gal

Top Speed

165-170 km/h
Reviews XLV owners
.

The Honda XLV750R was only in production for a few years, however it provided the basis and was the forerunner of the Transalp and Africa twin. The XLV750R was sold in Europe from 1983 -1986

The HONDA XLV 750 R has been sold from 1983 to 1986, as RD 01 type, as RD version first, presented in 'Salon de la Moto' in Paris in October 1982, and sold from July 1983, in RF version next, after some mechanical and aspect modifications, and sold from February 1985.

The major difference between the two versions is the painting , the RD version est 'rather flashy' in three colors : blue, white, red, while the RF version is 'rather invisible' en two colors : black + red or black + grey. In fact, the last bikes in RD version sold at the beginning of 1985 have received some of the modifications
planned for the RF version, as the adjustable rear suspension... and may be all or part of the mechanical modifications,

Why is it we always want what we can't have? With the '85 riding season in full swing, our shop is literally overflowing with high-tech two-wheelers, all of them highly desirable to a moto-maniac like myself.

I just couldn't stifle an envious sigh, however, when I saw photos of the Honda XLV750R. The styling of this corpulent Euro-cruiser instantly brought back fond memories of fast blasts on dual-purpose bikes through the mountains and deserts of the Imperial Valley in California. As luck would have it, American Honda just happened to have two in the U.S. for test purposes. After convincing our editor we should test one ("Ah, c'mon, it's not a real dirt bike") and Honda that we weren't just blowing smoke, I was off on a working vacation, bound for my ol' stomping grounds in the Imperial Valley.

My initial impression was disheartening. Only halfway to San Diego on the freeway, I already had a fault list as long as my arm. The XLVs stiff suspension lets you feel every bump and pavement ripple, and wide handlebars give the steering a twitchy feel. The seat is hard and narrow, inducing numb-butt within half-an-hour. Riding the stretch of interstate through the mountains and beaches of the Camp Pendelton Marine Base, I began to wonder what the attraction is for the thousands of Europeans who buy this ersatz enduro.

The guy in the Toyota truck enlightened me. When he wasn't pacing alongside, staring in open-mouthed disbelief, he was giving me a vigorous thumbs-up. He wasn't the only one. The radical look of the XLV was turning heads in rapid succession. I began to imagine myself touring rural European countryside, looking positively indestructible aboard the big Honda. So what if it's a little uncomfortable? Honda's intention was to imitate the look of the bikes that race from Paris, France, to Dakar, Africa, over a 6,500-mile on-and-off road route that requires barrel-sized gas tanks and the raw courage of a Viking.

Upwardly mobile Europeans idolize the wasteland conquerors who ride these awesome-looking machines, and imitate them on repli-bikes in the same way we ennoble the Lone Ranger image aboard stretched-out street cruisers.



Getting off the freeway and into the mountains provided further enlightenment. Although the five-speed gearbox ratios are a tad on the wide side, the 749cc, 45-degree V-twin engine delivers enough stump-pulling torque to forgive a misplaced shift. Combined with stiff suspension, a narrow seat and wide handlebars, the powerful motor gives the XLV canyon agility that belies its appearance. Suspension compliance on back roads is excellent. An air-assisted telescopic fork in front and Pro-Link monoshock out back perform flawlessly in the twisties, and the Dunlop Universal tires mounted front and rear-though they howl like knobbies - stick like slicks.

I was tempted to stay in the mountains and exploit the joys of the XLV amidst piney woods and gorgeous scenery, but the lure of the nearby desert proved too strong. Descending Banner Grade from Julian into the Ocotillo Wells area was like going home. Before moving to Los Angeles, I spent many weekends riding dirt bikes in the O.W. State Vehicle Recreation Area and the BLM land surrounding it.

Although the XLVs styling practically screams dirt from every pore, my first foray into the loose stuff proved this to be a skillful deception. The bike's considerable weight-due mostly to the big motor and conveniences like shaft drive and an electric starter-and street-biased tires make the XLV only a fair off -road performer. Flat fireroads and smooth hillclimbs are no problem; gobs of usable horsepower and straight-line stability let you cover this type of terrain at white-knuckle speeds

The rear shock absorber has a remote two-position damping adjuster-one position for street and the other for dirt that helps the rear end cope with the additional bumpiness of off-road riding.

Get into anything tighter than the open desert, however, and you'll wish you'd stayed home and mowed the lawn. I took the big bike through a narrow, rocky canyon, complete with tight corners and a sandv floor. After a hundred yards I'd dropped the bike twice. By the time I got out of the canyon I was covered in sweat and completely exhausted. Set up for the street, the XLV doesn't stand a chance in this kind of terrain, and even with the suspension pumped full of air and the damping turned up, the bike's weight soon overcomes the rider.

Honda doesn't use the XLV as a base bike for the Paris-Dakar rally-it's simply a styling exercise designed to appeal to the emotions of the non-racing European public. The race bikes are lightweight XR600 singles with custom-made gas tanks holding nine gallons or more. The gas tank on the XLV holds a modest 5.1 gallons, more than enough for a lengthy on/off road tour with the bike's 44 mpg average. Besides, the center of the tank is a great place for the airbox, swelling it to the appropriate styling dimensions and allowing an uncluttered engine bay.

Now in its third year of production, the XLV75OR continues to attract eager buyers in the 10 European countries in which it is offered. Honda swears it will never come to the U.S. What a shame. A bike that looks this good, has commendable street performance and enough off-road ability to suit the occasional trail blazer shouldn't be left standing at the gate. Perhaps a few years from now, when motorcyclists tire of the current crop of ultraspecialized streeters and long for something a little more versatile, we'll see more bikes like the XLV750R.

Source youngie.com
