Honda XLX 250R

.

Make Model

Honda XLX 250R

Year

1983

Engine

Four stroke, single cylinder, SOHC, 4 valve

Capacity

249 cc / 15.1 cu-in
Bore x Stroke 75 x 56.5 mm
Cooling System Air cooled
Compression Ratio 10.2:1

Induction

1x 28mm Keihin

Ignition

Electronic
Starting Kick
Clutch Wet multi-plate

Max Power

20.2 hp / 15 kW @ 7500rpm

Max Torque

19.6 Nm / 14.5 lb ft @ 8000 rpm

Transmission

6 Speed
Final Drive Chain

Front Suspension

Air assisted telescopic fork
Front Wheel Travel 210 mm / 8.2 in

Rear Suspension

Single shock, swing arm
Rear Wheel Travel 109 mm / 4.2 in

Front Brakes

Drum

Rear Brakes

Drum

Front Tyre

3.00 -21

Rear Tyre

4.60 -17

Wet Weight

 131.0 kg / 288.8 lbs

Fuel Capacity

9 Litres / 2.6 gal
.
