Indian Springfield

.

Make Model

Indian Springfield

Year

2018 - 19

Engine

Thunder Stroke™ 111 49˚ V-Twin

Capacity

1811.cc / 111 cu-in
Bore x Stroke 101 x 113 mm
Compression Ratio 9.5:1
Exhaust Split dual exhaust with crossover

Induction

Electronic Fuel Injection System Closed loop fuel injection / 54mm bore
Battery 1 2 volts / 18 amp/hour, 310 CCA
Charging System 42 amp max output

Starting

Electric

Max Toque

119.2 ft-lbs (161.6 N/m) @ 3000 rpm
Clutch Wet, Multi-Plate

Transmission

6 Speed
Final Drive Belt drive, 152 tooth
Gear Ratio 1st 9.403 : 1  2nd 6.411 : 1  3rd 4.763 : 1  4th 3.796 : 1  5th 3.243 : 1 6th 2.789 : 1
Final Drive Ratio 2.2 : 1
Primary Drive Gear drive wet clutch
Frame  Cast Aluminum Frame with Integrated Air-Box

Front Suspension

46mm Telescopic forks
Front Wheel Travel 119 mm / 4.7 in

Rear Suspension

Single Shock w/ Air Adjust
Rear Wheel Travel 114 mm /  4.5 in

Front Brakes

2x 300 mm Floating Rotor 4 piston calipers

Rear Brakes

Single 300 mm Floating Rotor 2 piston calipers
Brake System Type Individual front and rear control with ABS
Front Wheel Cast 19″ x 3.5″ with tire pressure monitoring
Rear Wheel Cast 16″ x 5.0″ with tire pressure monitoring

Front Tyre

Dunlop® American Elite 130/60B19 61H

Rear Tyre

Dunlop® Elite 3 180/60R16 80H

Rake 25°
Trail 133mm / 5.2 in
Ground Clearance 139.7 mm / 5.5 in
Dimensions Length 2522 mm / 99.3 in
Wheelbase 1700 mm  / 67.0 in
GVWR 630 kg / 1385 lbs
Seat Height 660 mm / 26.0 in
Ground Clearance 142 mm / 5.6 in
Dry Weight 349 kg / 770 lbs

Fuel Capacity

20.8 Litres / 5.5 US Gal

Pure and classic styling define the Indian Springfield®. In addition to getting Ride Modes and Rear Cylinder Deactivation, Indian Springfield® maintains rider-favorite features such as the quick release windshield, genuine leather seats, remote-locking saddlebags and adjustable passenger floorboards. ABS, cruise control, keyless ignition and tire pressure monitoring also come standard.

CRAFTED FOR STYLE. MADE TO PERFORM.
The Thunder Stroke® 111 is a soul-stirring V-Twin that delivers smooth, impressive power in every gear.  These models boast new features that take performance, customization and comfort to the next level – making it easier than ever to match your bike to your riding style. New ride-enhancing technology like selectable Ride Modes and Rear Cylinder Deactivation let you ride your way, with more comfort. Plus, new gloss black finishes on Dark Horse® models and an improved audio system on Roadmaster® make your ride look and sound better.

Developed in direct response to rider feedback, the new technology features focus on improving performance, comfort, and providing more customization. The new features include:

Selectable Ride Modes

Riders can now choose between three Ride Modes on the fly – Tour, Standard or Sport – for a ride experience that’s customized to their riding style. The throttle map for each Ride Mode was designed with a specific application in mind, resulting in one motorcycle with three distinct personalities. “Tour” mode features a smooth throttle response for relaxed cruising. “Standard” mode features a crisp throttle response and well-balanced power delivery for responsive passing power and predictable, slow-speed handling. And finally, “Sport” mode features an instant throttle response and aggressive power delivery for head-snapping acceleration.

Rear Cylinder Deactivation

To increase rider comfort, all Thunder Stroke® 111 models are now equipped with Rear Cylinder Deactivation. When the engine reaches operating temperature and the ambient temperature exceeds 59⁰ F, the rear cylinder will automatically deactivate when the bike is at a standstill, resulting in less engine heat for improved comfort in slow-moving or stopped traffic. The rear cylinder instantly reactivates when throttle is applied for a seamless transition to full power.

Improved Airflow on Roadmaster Lower Fairings

The lower fairings on the 2019 Roadmaster have been redesigned and optimized to provide significantly more airflow to the rider. This greatly improves comfort while cruising down the road. The redesigned airflow vent can be adjusted from all the way open for maximum airflow to fully closed for total weather protection. The new lowers can be retrofit to bikes from past model years with the addition of new highway bars.

Enhanced Audio System

Several enhancements have been made to Indian Motorcycle’s stock audio system to significantly improve sound quality. First, the tweeters have been separated from the mid-range speakers to optimize sound output and clarity. Second, a dynamic equalizer that’s fully customizable now adjusts specific frequencies at different vehicle speeds to provide peak system performance at all times. As speed increases, the equalizer automatically adjusts each frequency to the optimal level to compensate for road, wind and engine noise. The result is crystal clear, 100-watt premium audio at all speeds.

“These enhancements for 2019 showcase our commitment to listening to riders and continuously improving their experience with our products,” said Steve Menneto, President, Indian Motorcycle.  “We are laser-focused on delivering a best-in-class riding experience, and these new technologies represent a focus on quality that will continue long into the future of Indian Motorcycle.”

Also for 2019, Chief Dark Horse and Springfield Dark Horse receive several style updates that further accentuate their mean, custom styling. These models now boast premium gloss black finishes on the engine including the primary, valve, and cam covers, push-rod tubes, as well as on the exhaust and saddlebag hinges.

Springfield Dark Horse is now offered in two colors –Thunder Black Smoke and a new White Smoke option. Also, notable for the 2019 Springfield Dark Horse is the addition of the iconic Indian headdress on the front fender and a 19” contrast-cut wheel. The front highway bars and windshield were also removed to punctuate its sleek, streamlined stance.

Indian Motorcycle offers a wide range of authentic accessories for riders to customize their bike’s performance, style, comfort and storage. Exciting additions to the accessory line will be announced shortly.

Dark Horse® Updates
Also for 2019, Chief Dark Horse® and Indian Springfield® Dark Horse® receive several style updates that further accentuate their mean, custom styling. These models now boast premium gloss black
finishes on the engine including the primary, valve, and cam covers, push-rod tubes, as well as on the exhaust and saddlebag hinges.

Indian Springfield® Dark Horse® is now offered in two colors –Thunder Black Smoke and a new White Smoke option. Also, notable for the 2019 Indian Springfield® Dark Horse® is the addition of the iconic Indian Motorcycle® headdress on the front fender and a 19″ contrast-cut wheel.

The front highway bars and windshield were also removed to punctuate its sleek, streamlined stance.

Indian Motorcycle® offers a wide range of authentic accessories for riders to customize their bike’s performance, style, comfort and storage.

THUNDER STROKE® 111 ENGINE
The award-winning V-Twin delivers 119 ft-lbs of torque for quick acceleration and plenty of passing power in every gear. This impressive performance is paired with a distinctive, throaty rumble from dual exhaust pipes.

RIDE COMMAND®
It’s the largest, fastest, most customizable infotainment system on two wheels. The seven-inch Ride Command® system with a glove-compatible touchscreen display features turn-by-turn navigation, Bluetooth® connectivity, vehicle information and much more. It’s easy to customize your split-screen displays to only see what you want to see.

KEYLESS IGNITION
Keyless starting is secure and convenient. With an Indian Motorcycle® key fob in your pocket, just climb on the bike, push a button and take off. If you misplace the fob, use your customizable security code to start it up.

ADDITIONAL STANDARD FEATURES
All Thunder Stroke® 111 models are also equipped with automotive quality throttle-by-wire cruise control and a reliable anti-lock braking system. Chief® Vintage, Indian Springfield® and Roadmaster® also feature spacious saddlebags. Additionally, Chief® Vintage and Indian Springfield® feature a quick release windshield while Roadmaster® touts an adjustable power windshield.

PERFORMANCE UPGRADES
You can unleash more power, improve throttle response and get a deeper exhaust note with upgrades like Stage 1 Exhaust, a Thunder Stroke® High Flow Air Intake, and Stage 2 Performance Cams. For more style, add Six Shooter or Straight Exhaust Tips.

MID RISE HANDLEBAR
Add custom style, a comfortable reach, and loads of attitude with the Mid Rise Handlebar Kit. You’ll enjoy the riding position and the custom look.

EXTENDED REACH SEATS
Extended Reach Seats provide comfortable seating and improved ergonomics for taller riders and those who like to ride with their legs fully stretched out to the foot pegs and lower controls. The specially shaped cushioning in this seat elevates the rider to a higher seating position and sets the rider 2″ further back than the stock seating location.

APPAREL
Indian Motorcycle® is more than a brand name. It’s a symbol of everything we stand for. A rich heritage that, since 1901, has focused on one thing: the ride. With Indian Motorcycle® apparel, we stand united in that belief. T-shirts, jackets, boots, hats, helmets and more. Whether you’re riding or not, you can wear your heart on your sleeve.
