Zero FX

.

Make Model

Zero FX

Year

2017

Motor

Type Z-Force® 75-5 passively air-cooled, high efficiency, radial flux permanent magnet, brushless motor. Controller High efficiency, 420 amp, 3-phase brushless controller with regenerative deceleration

Power Pack

Z-Force Li-Ion intelligent modular

Maximum capacity

ZF 3.3: 3.3 kWh

ZF 6.5: 6.5 kWh

Nominal capacity

ZF 3.3: 2.9 kWh

ZF 6.5: 5.7 kWh

Estimated pack life (to 80%)

ZF 3.3: 148 000 km / 92 000 miles

ZF 6.5: 298 000 km / 185 000 miles

Charger Type

650W, integrated

Charge Time (standard)

ZF 3.3: 4.7 hrs (95%: 4.2 hrs)

ZF 6.5: 8.9 hrs (95%: 8.4 hrs)

With One Accessory Charger

ZF 3.3: 2.1 hrs ( 95%: 1.6 hrs)

ZF 6.5: 3.8 hrs (95%: 3.3 hrs)

With Max Accessory Chargers

ZF 3.3: 1.5 hrs (95%: 1.1 hrs)

ZF 6.5: 1.7hrs (95%: 1.2 hrs)

City Range

ZF 3.3: 66 km / 41 miles

ZF 6.5:  132 km / 82 miles

Maximum  Combined Range (City and Highway)

ZF 3.3: 39 - 50 km / 24- 31 miles

ZF 6.5:  79 - 100 km / 49 - 62 miles

Input Standard

110V or 220V

Max Power

ZF 3.3: 20 kW / 27 hp @ 4300 rpm

ZF 6.5: 34 kW / 46 hp @ 4300 rpm

Max Torque

106 Nm / 10.8 kgf-m / 78 ft-lb

Transmission

Clutchless direct drive

Final Drive

90T / 20T, Poly Chain HTD Carbon Belt

Front Suspension

Showa 41 mm inverted cartridge forks, with adjustable preload, compression and rebound damping

Front Wheel Travel

218 mm / 8.60 in

Rear Suspension

Showa 40 mm piston, piggy-back reservoir shock with adjustable spring preload, compression and rebound damping

Rear Wheel Travel

227 mm / 8.94 in

Front Brakes

Bosch Gen 9 ABS, J-Juan asymmetric dual piston floating caliper, Single 240 x 4.5 mm disc

Rear Brakes

Bosch Gen 9 ABS, J-Juan single piston floating caliper, Single 240 x 4.5 mm disc

Front Wheel

1.85 x 21

Rear Wheel

2.50 x 18

Front Tyre

Pirelli Scorpion MT 90 A/T 90/90-21

Rear Tyre

Pirelli Scorpion MT 90 A/T 120/80-18

Rake

25.4°

Trail

104 mm / 4.1 in

Wheelbase

1438 mm  /  56.6 in

Seat Height

881 mm / 34.7 in

Curb Weight

ZF 3.3: 112kg / 247 lbs

ZF 6.5: 131 kg / 289 lbs

Carrying capacity

ZF 3.3: 174 kg / 383lbs

ZF 6.5: 155 kg / 341 lbs

Acceleration 0 - 100 km/h / 60 mph

ZF 3.3: 4.3 sec

ZF 6.5: 4.0 sec

Top Speed

137 km/h / 85 mph

Top Speed (sustained)

113 km/h / 70 mph

Do Anything. Ride Anywhere.
You’ve never experienced power and freedom like this. All those things you wished you could get away with...they just became possible. It is said, “Absolute power corrupts absolutely.” Just in case you find this to be true, hit the eco-switch...or don’t.

Delivering a nearly instantaneous 78 ft-lb of torque and weighing less than 300 lb, the Zero FX takes any type of riding to bold new levels. Stealthily ride at any hour of the day or night, on a motorcycle that distills riding into its most basic and adrenaline-pumping elements.

Tempting you to ride on any terrain that crosses your path, the Zero FX chassis hails from Zero Motorcycles’ championship-winning off-road heritage and features the most advanced Z-Force® technology yet.

Equipped with a maintenance-free powertrain, belt drive and optional fully modular power pack system, no riding time is wasted and each mile ridden only costs around a penny in electricity.

Showa suspension
» Every Zero is now fully equipped with Showa suspension
» Exceptionally smooth action for improved comfort and control
» Fully adjustable settings to meet the demands of a wide variety of riders
» Increased torsional rigidity on the front end for improved handling
» Hollow front axle for reduced unsprung weight
» Durable and highly protective new fork guards on the Zero DS and Zero FX
» Developed in close collaboration with Showa

Bosch anti-lock braking system (ABS)
» Advanced Bosch ABS is now standard on every model
» ABS can be switched on or off depending on rider’s preferences
» Incredibly smooth actuation for improved control under extreme braking
» Larger 320 mm carrier-less front rotor increases stopping power on the Zero S, Zero SR and Zero DS
» New braking systems with refined hydraulic ratios for improved braking power and modulation
» Adjustable front brake lever for customizable ergonomics on the Zero S, Zero SR and Zero DS

 Up to 185 miles with higher energy density
» The Zero S and Zero SR city range can now be extended to 185 miles using the Power Tank accessory
» Newly packaged battery cell offers 10% more energy density on the Zero S, Zero SR and Zero DS

New wheels and Pirelli tires across the entire lineup
» New cast alloy wheels on the Zero S, Zero SR and Zero DS
» New high performance Pirelli tires for every model combine excellent grip with long lasting mileage
» The Zero S, Zero SR and Zero DS wheels are now equipped with a larger carrier-less front rotor to reduce unsprung weight and increase stopping power
» The Zero SR now uses softer compound Diablo Rosso II tires for even greater traction
» The Zero FX now features wider 1.85 x 21 front and 2.50 x 18 rear wheels and tires for increased strength and greater aftermarket tire options
» Larger, higher-capacity wheel bearings on every model to increase stiffness, versatility and durability

 Improved rider interface
» Stylish new mirrors provide great visibility while also reducing motorcycle width
» Comfortable new grips use a softer rubber compound
» Newly contoured seat for improved ergonomics on the Zero S, Zero SR and Zero DS
» New throttle for improved action

Game Changing Z-Force® Power Pack

A fully modular system

The Zero FX features a fully modular power pack system. With slots for two power packs, you can operate the Zero FX with either one or both slots filled. The modules can be charged either on the motorcycle or elsewhere using optional accessories, giving you the ability to charge without a street-level outlet.

The Zero FX can be purchased with either one module (ZF3.3) or two modules (ZF6.5).



Revolutionary Z-Force® Motor

Thrilling acceleration with 78 ft-lbs. torque

The motor in the Zero FX is configured to produce incredible torque and sits inside the lightest motorcycle in the lineup. The result is thrilling acceleration. Zero Motorcycles designed the Z-Force® motor from the ground up to be compact, efficient and powerful. Completely air-cooled, the motor is designed to provide a fantastic riding experience minus the need for any regular maintenance. When slowing down, the motor generates electricity that is channeled back into the power pack to help extend ride times.


Charge Anywhere

Plug in at any standard outlet

The Zero FX charging system is integrated into the motorcycle and can be plugged in at any standard outlet. No additional equipment is required for standard charging. This allows you to conveniently charge in your garage, at the office or when you stop at one of your favorite places while enjoying a day out.

The Zero FX power pack modules can be removed from the motorcycle and charged separately using optional accessories. This makes it possible to charge the modules anywhere you take them and thereby eliminates the necessity of a street-level outlet. Charging times can be reduced by up to ~75% by using a scalable off-board charging system.

Frame and Bodywork

Light Aircraft Grade Aluminum

At the core of the Zero FX lies the ultimate dirt bike frame that Zero engineered from the ground up and hand-crafted using aircraft grade aluminum. The resulting combination of lower weight and higher strength means more responsiveness. In the corners and off the line, this translates into greater acceleration. To make the frame even more durable, each frame is shot-peened and anodized.


Showa Suspension

The Magic Ride

Zero worked in close collaboration with Showa to develop suspension systems that provide excellent small bump compliance, predictable control of bigger impacts and exceptionally smooth action under all conditions. Torsional rigidity of the front end improves handling, and a hollow front axle reduces unsprung weight. Suspension settings are completely customizable to meet the demands of a wide variety of riders.


Bosch Anti-lock Brake System (ABS)

Powerful. Precise. Control.

The Zero FX features an advanced Bosch anti-lock brake system (ABS) that improves control in a wide array of conditions and ensures the best braking performance.


Wheels and Tires

Paved Road. Dirt Road. No Road.

Pirelli tires are standard on the Zero FX, providing improved traction in a wide variety of conditions, excellent durability and road feel. The Zero FX alloy wheels are designed to reduce unsprung weight while not compromising on strength.


Direct Drive Gearing

Instant torque with a twist



Featuring a clutchless direct drive, the Zero FX is geared for rapid acceleration and maximum efficiency. Without ever needing to shift, the Zero FX provides controlled and powerful acceleration at any speed between 0-85 mph. The carbon fiber belt achieves minimal frictional losses for increased overall range and is integral to making the powertrain maintenance-free.


Dash and Controls

Impressive information. Elegantly Displayed.

The dash is designed by Zero to quickly and accurately provide useful data on such information as state of charge, power output and your selected riding profile. You can toggle through three riding profiles using the ergonomic right-hand switch gear to better meet the needs of your ride: Sport, Eco, Custom. The dash screen features a cool blue backlit LCD display and integrates seamlessly into the front of the motorcycle. Want more information about the motorcycle while riding or at home? Try the Zero Motorcycles App.
