Aprilia SMV 750 Dorsoduro

.

Make Model

Aprilia SMV 750 Dorsoduro

Year

2007

Engine

Four stroke, longitudinal 90°V twin, DOHC, 4 valves per cylinder

Capacity

749.9 cc / 45.7 cu-in
Bore x Stroke 92 x 56.4 mm
Compression Ratio 11.0:1
Cooling System Liquid cooled
Exhaust 2 into 1 exhaust system in 100% stainless steel with three-way catalytic converter and lambda probe
Lubrication Wet sump

Induction

Integrated engine management system. Latest generation 3 maps (Sport, Touring, Rain) Ride-by-Wire throttle management.

Ignition

Digital electronic, integrated with the injection, two spark plugs per cylinder
Starting Electric

Max Power

67.3 kW / 92 hp @ 8750 rpm

Max Torque

82 Nm / 8.36 kgf-m / 60.4 lb/ft / @ 4500 rpm
Clutch Multiplate wet clutch, hydraulically operated

Transmission

6 Speed
Final Drive Chain
Gear Ratio 1st 36:14 (2.57) / 2nd 32:17 (1.88) / 3rd 30:20 (1.5) / 4th 28:22 (1.27) / 5th 23:/26 (0.88) / 6th 24:25 (0.96)
Frame Modular steal trellis secured to albumin side plates by high steal bolts.

Front Suspension

Ø43 mm Upside-down fork.
Front Wheel Travel 167 mm / 6.5 in

Rear Suspension

Aluminium alloy swingarm with reinforcement truss. Hydraulic shock absorber adjustable in spring preload and rebound damping.
Rear Wheel Travel 150 mm / 5.9 in

Front Brakes

2 x Ø320 mm discs, 4 piston caliper

Rear Brakes

Single Ø240 mm disc, 1 piston caliper
Wheels Aluminium alloy

Front Wheel

3.5 x 17

Rear Wheel

6.00 x 17

Front Tyre

120/70  ZR17

Rear Tyre

190/5ZR17
Dimensions

Length  2216 mm / 8732 in
Width      905 mm / 35.6 in
Height   1185 mm / 46.6 in at instrument panel

Seat height 870 mm / 34.2 in

Dry Weight

186 kg / 409 lbs

Fuel Capacity

12 Litres / 3.17 US gal

Consumption Average

5.3 L/100 km / 18.8 km/l / 44.2 US mpg
Standing 0 - 100 km/h 3.9 sec
Standing 0 - 140 km/h 7.1 sec

Standing ¼ Mile

12.8 sec
Acceleration  60-100 km/h 4.5 sec
Acceleration  60-140 km/h 9.5 sec
Acceleration  100-140 km/h 7.1 sec

Top Speed

202.9 km/h / 126 mph
.

 The Aprilia SMV 750 DORSODURO is an extreme motorcycle for the extreme rider, the rider who refuses all compromise in his quest for the best.

Once again Aprilia has amazed the motorcycling world with another highly innovative design, destined to dominate the maxi motard segment. The Aprilia SMV 750 DORSODURO is not just another twin cylinder motard, but a motorcycle that embodies all of Aprilia’s vast experience in competitive supermotard racing, a speciality in which Aprilia has so often dominated the competition.

The ultimate mix of incredible agility, sports performance, essential styling and quality build, and combines features taken from the worlds of supersport and supermotard motorcycles (including top competition machines). This concentration of performance and technology is build for absolute riding satisfaction and fun. A special bike indeed, extreme and elite, the SMV 750 elevates its rider to the class of a true professional.

A riding position carefully calculated to deliver total control, a mighty 95 horsepower engine and an amazingly agile chassis are the distinctive features of the Aprilia SMV 750.

No bland machine for the masses, but a true thoroughbred that only expert riders can really appreciate, the SMV 750 carries you into a world of high performance and even higher emotions that very few other motorcycles can enter. Graced with the agile handling of all motards, the SMV 750 adds a level of power normally only found on road-going supersports.

An advanced engine and an exceptional chassis (typical of all Aprilia motorcycles) are the trump cards of the SMV 750, which also boasts sporting looks and a level of agility never before experienced on a twin.

Lightweight, agile, and powerful, the SMV 750  benefits from a new generation of engine and some of the most advanced technical solutions found on any motard. Thanks to advanced electronics, its compact 90° V twin engine delivers power that rivals or exceeds that of many larger twins. And as Aprilia traditions demand, the chassis is simply unrivalled. Developed to deadly effect on the super-specialist SXV, this mixed steel trellis and aluminium frame has become the hallmark of Aprilia motards. With technical specifications far in advance of the competition, this frame sets new standards for rigidity and agility.

But ‘essential’ certainly does not mean ‘basic’ on the Aprilia SMV 750 DORSODURO. Components and performance are prestigious and the level of finish is worthy of a true flagship model. Radial calipers, hydraulic clutch, ride-by-wire engine control, wave discs, and matrix instrumentation with on board computer all combine to make the SMV 750  unique.

With a power to weight ratio of a pure sports bike, the Aprilia SMV 750  can thrill even the most performance-hungry rider.

Let’s look at the features of the Aprilia SMV 750 DORSODURO in greater detail:

  • 90° V twin engine with four-valve heads, double overhead cam and liquid cooling

  • Ride-by-wire controls

  • Electronic fuel injection with the latest generation of injectors

  • Mixed gear and chain timing drive

  • Three way catalytic converter with Lambda probe

  • Compound steel trellis and aluminium alloy frame for extremely light weight and high torsional rigidity

  • Aluminium alloy swingarm with offset monoshock

  • Fully adjustable 43 mm upside down fork

  • Racing brakes with radial front calipers

 On essential machines like the Aprilia SMV 750, the minimalist and aggressive bodywork is nothing more than a frame for motorcycling technology, with engine and chassis becoming central to the overall design. The SMV 750  is a radical, acrobatic, sports motorcycle with no space for frills or parts that are not essential to delivering maximum riding pleasure. That is why body panels are reduced to a minimum. Just like a real racing machine, the SMV 750 DORSODURO eliminates everything the rider does not actually need, including passenger footrests (available as an optional accessory). And no frills means a clear view of the bike’s amazing technical components.

The Aprilia SMV 750  is a concentration of pure technology, as you can clearly see from its mean, sporting lines. And aggression is expressed not only through masses of power and torque, but through extreme agility too. Though every part on the SMV 750  is designed to be as light as possible, finish and quality are nevertheless superb. The Aprilia SMV 750 is built to satisfy its rider in every sense of the word.



The centre of the bike is impressively compact to facilitate movement under sports riding conditions. The rider really does become an integral part of the machine, shifting weight effortlessly to control power output under all riding conditions, even on circuits where classic motard wheelies and power slides are the order of the day.

The Aprilia SMV 750 is incredibly slim and agile, with a riding position that puts you in total control. It only takes a few metres on a SMV 750  to learn how to control the bike exactly as you want, and to develop a perfect symbiosis between man and machine.

The knife-sharp tail houses a twinned exhaust, a solution that not only gives the bike a mean, aggressive look but also achieves perfect symmetry and ideal weight distribution.


Aprilia’s generous and ultra-modern V90 engine has already established itself as a leader in performance and technology.

On the SMV 750  various aspects of the engine have been modified to adapt power delivery to suit the acrobatic nature of the bike. Endless hours of bench and road testing have led to the definition of an ideal mapping, allowing this twin cylinder power plant to set new records for its size and to surpass many engines of far greater displacement too.

A quick glance is all that is required to reveal the engine’s main features:

  • 90° V twin layout

  • Ride-by-wire control technology

  • Very over-square bore to stroke ratio

  • Four valves per cylinder

  • Double overhead cam with mixed gear and chain timing drive

  • Electronic fuel injection with two throttle bodies

  • Stick-coils integrated in the spark plug caps

  • Three way catalytic converter and Lambda probe

  • Hydraulically operated clutch

The latest generation injection system uses micro-spray injectors. Combined with optimised fluid dynamics, this solution ensures optimal combustion for maximum power and an extremely clean burn.

Sophisticated electronic engine management establishes the Aprilia SMV 750 DORSODURO as the supermotard the others have to beat when it comes to performance.

Aprilia was the first manufacturer to use ride-by-wire technology on a motorcycle. This sophisticated technical solution is not intended to replace rider input but to assist the rider in getting the very best possible performance from his motorcycle. The Aprilia SMV 750 DORSODURO is equipped with the second generation of electronic throttle control. More precise and sophisticated mapping also contributes to improved engine management. Ride-by-wire control optimises throttle opening on the basis of a number of parameters, including engine speed, the gear selected, air flow, twist grip position, and temperature. The engine is therefore always able to deliver its best performance in acceleration by adjusting its torque curve to give a more satisfying and thrilling ride. The advanced electronic technology on the SMV 750  also delivers smoother and fuller power at low to medium engine speeds, optimising the functioning of the engine at low loads, when the throttle is only partly open.



Thanks to its high-tech systems, Aprilia’s V90 engine delivers an amazing 95 hp at 9,000 rpm with 8.25 Kgm of torque at 7,000 rpm, record values for a 750 cc twin. This level of engine performance places the Aprilia SMV 750 DORSODURO in direct competition with many bikes powered by far bigger engines.

A latest generation ECU manages all engine parameters, with a CAN network carrying all signals to an instrument cluster that incorporates a self-diagnostic terminal. The CAN line uses only two wires to handle all data, dramatically simplifying the electrical system and reducing the overall weight of the motorcycle.

The exhaust is made entirely from stainless steel. The collector pipes meet in a single silencer under the seat before splitting again into two tail pipes. The large volume of the exhaust system also aids engine breathing and boosts efficiency.
