| Aprilia SX 125
|
. |
Make Model |
Aprilia SX 125 |
Year |
2012 - |
Engine |
Two stroke, single cylinder Aluminium cylinder with Nikasil coated liner. Read valve intake. Separate mixing. Homologated to Euro 3 standard. |
Capacity |
125 cc / 7.6 cu-in |
Bore x Stroke | 54 x 54.5 mm |
Compression Ratio | 12.5:1 |
Cooling System | Liquid cooled |
Induction |
Dell’Orto VHST 28 |
Ignition |
Electronic CDI |
Starting |
Kick |
Max Power |
16.4 kW / 22 hp |
Max Torque |
16.0 Nm / 1.6 kgf-m / 11.8 ft-lb |
Transmission |
6 Speed |
Final Drive |
Chain |
Gear Ratio |
1st 10:30 / 2nd 14:29 / 3rd 17:27 / 4th 19:25 / 5th 21:23 / 6th 22:21 |
Frame |
High strength steel frame with double trellis beam and double cradle. Separate seat frame. |
Front Suspension |
Upside down telescopic fork, Ø40 mm |
Front Wheel Travel |
260 mm / 10.2 in |
Rear Suspension |
Steel swingarm. Hydraulic monoshock with piggy back cylinder |
Rear Wheel Travel |
270 mm / 10.6 in |
Front Brakes |
Single 260 mm disc, sliding 2 piston caliper, Brembo |
Rear Brakes |
Single 220 mm disc, sliding 1 piston caliper |
