BMW K1600GTL Exclusive

.

Make Model

BMW K 1600 GTL Exclusive

Year

2014 - 15

Engine

Four stroke, transverse six cylinder, 4 valves per cylinder

Capacity

1649 cc / 100.6 cu in.
Bore x Stroke 72 x 67.5 mm
Compression Ratio  12.2:1
Fuel Premium unleaded (95 RON)
Cooling System Liquid cooled

Induction

52mm Throttle valve diameter, BMS-X

Ignition

Digital CDI
Alternator 580 W Alternator
Battery 12 V / 19 Ah maintenance free
Starting Electric

Max Power

118 kW / 160.5 hp @ 7750 rpm

Max Torque

175 Nm / 17.8 kgf-m / 129 lb-ft @ 5250 rpm

Clutch Multiplate wet clutch, hydraulically activated

Transmission

6 Speed
Final Drive Shaft
Gear Ratio 1st 2.23 / 2nd 1.641 / 3rd 1.319 / 4th 1.101 / 5th  0.926 / 6th 0.788
Frame

Chill-cast rear frame, aluminium, extruded sections

Front Suspension

Dual longitudinal control arm
Front Wheel Travel 115 mm / 4.8 in

Rear Suspension

Paralever (single-sided swing arm), central spring strut, rebound/continuously variable
Rear Wheel Travel 135 mm / 5.3 in

Front Brakes

2 x ∅320mm discs, 4 piston calipers

Rear Brakes

Single ∅320mm disc, 2 piston caliper
ABS BMW Motorrad ABS (partial integral)

Front Tyre

120/70 ZR17

Rear Tyre

190/55 ZR17
Front Rim 3.0 x 17"
Rear Rim 6.00 x 17"
Wheels Cast aluminium wheels
Castor 108.4 mm / 4.3 in
Steering Head Angle 62.2°
Wheelbase 1680 mm / 66.1 in
Dimensions Length: 2489m m / 98.0 in
Width: 1000 mm / 39.4 in
Height: 1465 mm / 57.7 in
Seat Height 810 - 830 mm / 31.9 - 32.7 in (standard)
780 - 800 mm / 30.7 - 31.5 in(optional rider seat)
750 mm / 29.5 in (special accessory seat, single-section)
Dry Weight 321 kg / 708 lbs

Wet Weight

348 kg / 768 lbs

Fuel Capacity

26.5 Litres / 7.0 US gal
Reserve 4 Litres / 1.1 US gal
.

For 2014, BMW have announced a new iteration of the K1600 tourer – the K1600 GTL Exclusive. Still powered by BMW’s 175Nm, 160-horsepower inline-six, the K1600 GTL gets more equipment as standard – central locking with anti-theft alarm, ESA II electronic suspension adjustment, traction control (DTC), ABS, hill start control and even a ‘film antenna’ for the radio that is embedded in the topcase lid.

The 2014 K1600 GTL also gets a new, redesigned seat, revised instrumentation, heated backrest and comfortable armrests, LED auxiliary headlights and DRLs, adaptive xenon headlights, a tyre pressure monitor, engine protection bar, fully chromed exhaust system, floor lighting and, for the first time on a BMW motorcycle, ‘Keyless Ride.’

As befits the K1600 GTL Exclusive’s top-of-the-range luxury tourer status, the bike gets a new, high-gloss “mineral white” paintjob, with contrasting shades of magnesium metallic matt and silver metallic radiator fins, plus colour-coordinated upholstery for the seat cushions, backrest and pillion passenger armrests.

When dynamic performance meets luxury, the result is always exclusive and sensational. BMW Motorrad presents the K 1600 GTL Exclusive – a high-class touring bike that takes technology and visual styling to the extreme. This GTL makes all 6-cylinder dreams come true.

The BMW K 1600 GTL Exclusive takes two-wheeled travel to a whole new level thanks to a 118 kW (160 hp) in-line six-cylinder engine that melds superlative power with exemplary refinement, as well as boasting superb standards of equipment and comfort.

Spearheading the BMW Motorrad tourer range, the “Exclusive” model already lays claim to a class-beating specification as standard, including central locking with anti-theft alarm system and ESA II electronic suspension adjustment for an optimum spring/damper setup regardless of load. The Dynamic Traction Control (DTC) boosts safety when accelerating, while the innovative new Hill Start Control feature takes all the hard work out of pulling away uphill, even when carrying a passenger and luggage. Needless to say, the K 1600 GTL Exclusive also comes equipped with BMW Motorrad ABS as standard, like all BMW motorcycles.

The film antenna for the radio that is embedded in the topcase lid is a world first and ensures the best possible reception quality while also enhancing the bike’s appearance. Long-distance travel comfort for the pillion passenger is taken to greater heights by a new seat, the heated backrest and comfortable armrests. Also to be found on the list of standard equipment are LED auxiliary headlights, adaptive xenon headlight, Tyre Pressure Monitor, additional brake light, engine protection bar, floor lighting, as well as LED daytime running light and, for the first time on a BMW motorcycle, Keyless Ride.

The styling of the “Exclusive” model likewise spells pure luxury – from the fuel tank’s aluminium moulding through the fully chromed exhaust system to the new-look instrumentation.

The colour scheme for the new K 1600 GTL Exclusive adds to the sense of elegance and aesthetic appeal. The bodywork’s four-coat paint finish in Mineral white metallic high gloss combines to striking effect with the classy chrome surfaces, the contrasting shade of Magnesium metallic matt and the Glacier silver metallic radiator fins. The colour-coordinated upholstery for the seat cushions, backrest and pillion passenger armrests adds the perfect finishing touch.

Key Features

•Superior in-line six-cylinder engine with abundant pulling power, especially at low and medium revs.
•Output of 118 kW (160 hp) at 7,750 rpm and maximum torque of 175 Nm (129 lb-ft) at 5,250 rpm.
•Over 70 per cent of maximum torque on tap from just 1,500 rpm.
•Three selectable riding modes (“Rain”, “Road”, “Dynamic”).
•High standard of active safety thanks to BMW Motorrad Integral ABS (part integral).
•Dynamic Traction Control (DTC) to maximise safety when accelerating.
•Chassis featuring duolever and paralever suspension plus ideal concentration of mass for dynamic handling abilities combined with the best possible comfort.
•Electronic Suspension Adjustment II (ESA II) for optimum adaptation to all operating requirements and vehicle loads.
•New instrumentation scales and sophisticated chrome surfaces. (New!)
•Instrument cluster with extended functionality. (New!)
•Larger seat area, armrests and new heated backrest to offer pillion passengers the best possible comfort. (New!)
•Liners for cases and topcase (embroidered).
•Keyless Ride and central locking to maximise ease of use and security. (New!)
•Hill Start Control enabling pulling away uphill with ease and comfort. (New!)
•Integral film antenna for optimum radio reception and exclusive styling. (World first!)
•Adaptive xenon headlight for greater safety on night-time rides.
•LED daytime running light. (New!)
•LED auxiliary headlights.
•Floor lighting.
•Audio system with preparation for navigation device and controllable interface for iPod, MP3, USB, Bluetooth and satellite radio (satellite radio only available in USA and Canada).
•Innovative design offering outstanding wind and weather protection.
•Elaborate, exceptionally high-grade four-coat paint finish. (New!)
•Extensive equipment and bespoke accessories made to BMW Motorrad’s customary high standards.

Hill Start Control
Heated Passenger Backrest
Passenger Arm Resets
Ground Lights
Crash Bars
2nd Brake Light
Dynamic Traction Control
Adaptive Cornering Lights
LED auxilary Headlights
Electronic Suspension Adjustment
Central Locking and Anti-Theft alarm
Keyless Ride
Daytime Running Light
Radio Film Aerial (embedded in the lid of the top case)
Liners for Panniers and Top Box

Features and Benefits

The design: a perfectly crafted masterpiece.

"Exclusive" at first sight: four layers of Mineral white metallic high-gloss paint give the outer skin of the GTL Exclusive a level of quality and depth which is unparalleled. Mineral white metallic is seamlessly blended with gentle Magnesium metallic matte and supplemented with numerous surfaces finished in chrome, seats and upholstery in Magnesium silver and a wealth of other details – the GTL Exclusive radiates luxury and dynamic performance from every angle.

The technology: only the best.

The GTL Exclusive also features the silken-soft yet powerful in-line 6-cylinder. Its exclusivity lies in the detail: Hill Start Control for moving off effortlessly on slopes, Keyless Ride automatically releases the steering lock, ignition, fuel tank lid and alarm system as soon as the key is within two meters of the motorcycle. The radio foil aerial antenna is integrated invisibly in the body and the Adaptive headlight with xenon technology enhances visibility and safety.

The equipment: uncompromising.

The equipment options assembled for the GTL Exclusive are those most frequently in demand among motorcyclists. Central locking with alarm system and a heatable seat with backrest come as standard. ESA II, DTC, RDC, LED auxiliary lights, adaptive xenon headlight, a second brake light and ground lighting are included for travel comfort. The functions of the BMW on-board computer Pro have been improved and an engine guard is incorporated as standard.
