2020 BMW R nineT

.

Make Model

BMW R nineT

Year
2020

Engine

Four stroke, two cylinder horizontally opposed Boxer, two camshafts and four radially aligned valves per cylinder, central counterbalancer shaft.

Capacity

1170 cc / 71.4 cub in.

Bore x Stroke
101 x 73 mm

Cooling System Air/Oil cooled

Compression Ratio 12.0:1

Lubrication Wet sump

Induction

Electronic intake pipe injection / digital engine management with overrun cutoff, twin-spark ignition

Emission Control Controlled 3-way catalytic converter, exhaust emission standards EU-4

Alternator Three-phase alternator 600 W

Battery 12 V / 14 Ah, maintenance-free

Starting
Electric

Max Power
81 kW / 110 hp @ 7550 rpm

Max Torque

116 Nm / 11.8 kgf-m / 85.6 lb-ft @ 6000 rpm

Clutch Single dry plate clutch, hydraulically operated

Transmission

Constant mesh 6-speed

Final Drive Shaft

Gear Ratios Ist 2.375 / 2nd 1.696 / 3rd 1.296 / 4th 1.065 / 5th 0.939 / 6th 0.848:1

Frame

Four-part frame concept with front frame and three-part rear frame, load-bearing engine-gearbox unit, rear-seat frame removeable for one-up riding

Front Suspension

Upside-down telescopic forks, 46 mm fixed-fork-tube diameter

Front Wheel Travel 120 mm / 4.7 in

Rear Suspension

Cast aluminium single swinging arm with BMW Motorrad Paralever; central spring strut,spring preload fully adjustable by hook wrench, adjustable rebound-stage damping

Rear Wheel Travel 120 mm / 4.7 in

Front Brakes
2 x 320 mm Foating brake discs, 4 piston radial calipers

Rear Brakes
Single 265 mm disc, 2 piston floating caliper

ABS BMW Motorrad ABS

Rim Front 3.50 x 17, Cast alloy

Rim Rear 5.50 x 17, Cast alloy

Front Tyre
120/70 - ZR17

Rear Tyre

180/55 - ZR17

Castor 107.9 mm / 4.2 in

Steering Head Angle 63.2 °

Dimensions

Length 2110 mm / 83.1 in
Width 900 mm / 35.4 in (incl. mirrors)
Height 1240 mm / 48.8 in (excl. mirrors)

Wheelbase 1522 mm / 59.9 in

Seat Height 820 mm / 32.3 in

Inner Leg Curve 1795 mm / 70.7 in unladen

GVWR 430 kg / 948 lbs

Dry Weight

220 kg / 485 lbs

Fuel Capacity

18 Litres / 4.7 US gal / 3.7 Imp gal

.

The R nineT has an uncomplicated style but nevertheless a completely unmistakable presence. It embodies the passion and innovation of over 90 years of motorcycle construction – naturally together with the classic BMW Motorrad proportions: striking boxer engine, compact tank, slim rear. All materials are of consistently high quality; the surfaces are carefully refined. Added to this is an immense attention to detail and real craftsmanship. The fender for instance is screwed to the fork feet using two forged brackets. And the headlamp holder is made out of aluminum.

BMW R nineT – the essence of 90 thrilling years of BMW Motorrad.

The BMW R nineT, which has been created to mark “90 years of BMW Motorrad”, radiates purism and power in undisguised form. It skilfully blends the boxer engine’s rugged character and the design traits of various motorcycle eras with cutting-edge technology and a modular concept that offers the rider maximum scope for personalisation. Strictly reduced to the essentials, the BMW R nineT – or just nineT for short – is made all the more alluring by its hand-built feel and strong emotional appeal.

The classic roadster bike is built to cater to the many motorcycle enthusiasts who yearn for unadulterated, stress-free riding pleasure. When it came to developing the design of the nineT in particular, terms such as “puristic simplicity”, “emotion” and “authentic, traditional materials” were also high on the list of priorities. Styling cues from old-school motorcycle manufacture are thus united with the very latest drive and chassis components on the nineT to produce a sensational motorcycle that is just as adept at cruising along serenely as it is at powering down country roads.

Puristic design.

Hand-built feel of the workmanship.
Air/oil-cooled twin-cylinder boxer engine with a displacement of 1,170 cc. Output 81 kW (110 hp) at 7,750 rpm, maximum torque 119 Nm (88 lb-ft) at 6,000 rpm.
Ideally suited to customisation.
Modular frame concept with removable pillion frame and frame end-piece.
Classic wheel suspension concept using high-quality upside-down telescopic fork at the front and paralever at the rear.

Exhaust system with two silencers on the left-hand side, with variation options.
Traditional wire-spoke wheels with black rims and hubs.
Radial 4-piston monoblock brake callipers, steel-braided brake lines and floating 320 mm brake discs.
Model plate riveted onto steering head in classic BMW Motorrad style.
Bespoke range of special accessories made to BMW Motorrad’s customary high standards of quality.
