BMW R nineT Urban G/S

.

Make Model

BMW R NineT Urban G/S

Year

2017 - 18

Engine

Four stroke, two cylinder horizontally opposed Boxer, two camshafts and four radially aligned valves per cylinder, central counterbalancer shaft.

Capacity

1170 cc / 71.4 cub in.

Bore x Stroke

101 x 73 mm
Cooling System Air/Oil cooled
Compression Ratio 12.0:1
Lubrication Wet sump
Induction Electronic intake pipe injection / digital engine management with overrun cutoff, twin-spark ignition
Emission Control Controlled 3-way catalytic converter, exhaust emission standards EU-4
Alternator Three-phase alternator 720W
Battery 12 V / 14 Ah, maintenance-free

Starting

Electric

Max Power

81 kW / 110 hp @ 7550 rpm

Max Torque

116 Nm / 11.8 kgf-m / 85.6 lb-ft @ 6000 rpm

Clutch Single dry plate clutch, hydraulically operated

Transmission

Constant mesh 6-speed

Final Drive Shaft
Gear Ratios Ist 2.375 / 2nd 1.696 / 3rd 1.296 / 4th 1.065 / 5th 0.939 / 6th 0.848:1
Frame Three-part frame concept with front frame and two-part rear frame, load-bearing enginegearbox unit, rear-set frame removeable for one-up riding

Front Suspension

Telescopic forks, 43 mm fixed-tube diameter

Front Wheel Travel 125 mm / 4.7 in

Rear Suspension

Cast aluminium single swinging arm with BMW Motorrad Paralever; central spring strut,spring preload fully adjustable by hook wrench, adjustable rebound-stage damping

Rear Wheel Travel 140 mm / 5.5 in

Front Brakes

2 x 320 mm Foating brake discs, 4 piston radial calipers

Rear Brakes

Single 265 mm disc, 2 piston floating caliper
ABS BMW Motorrad ABS
Rim Front 3.00 x 19, Cast alloy
Rim Rear 4.50 x 17, Cast alloy

Front Tyre

120/70 - R19

Rear Tyre

170/60 - R17

Castor 110.6 mm / 4.4 in
Steering Head Angle 61.5 °
Dimensions Length 2175 mm / 85.6 in
Width     870 mm / 34.3 in
(incl. mirrors)
Height  1330 mm / 52.4 in  (excl. mirrors)
Wheelbase 1527 mm / 60.1 in
Seat Height 850 mm / 33.5 in unladen
Inner Leg Curve 1890 mm / 74.4 in unladen
GVWR 430 kg / 948 lbs
Dry Weight 209 kg / 461 lbs

Wet Weight

221 kg / 487 lbs

Fuel Capacity

17 Litres / 4.8 US gal

Reserve

3 Litres / 0.8 gal

.

When BMW launched the R nineT back in 2013, few could have predicted what a rampant success story it would become – and even fewer would have predicted the four versions that have arrived since: the Scrambler, Racer, Pure, and now this – the Urban G/S.

The NineT Urban G/S comes as an homage to the original 1980 R80G/S, the first large displacement adventure bike that spawned what has become one of the most important categories of motorcycles.

The Urban G/S slots in next to the new R nineT Pure as being a little more budget friendly, getting cheaper suspension and components than the well-kitted original Roadster. ABS does come standard, but traction control (aka BMW's Automatic Stability Control) will cost extra.

Highlights

  • Tribute to original R80G/S
  • 1170cc air-cooled boxer twin
  • Alloy cast wheels
  • ABS as standard
  • Optional traction control

The facts

  • 110bhp
  • 221kg
  • Seat height 850mm

There are plenty of forged aluminium parts including the fork bridges, fat handlebar and bar clamp. The footrests also mirror the G/S’s off-road styling with bear-claw pegs fitted with removable rubber inserts, and the simple stainless exhaust system is classy and sleek. There’s also a cute double front mudguard, with an MX-style main fender complemented by a shorter wheel-level deflector.

But what really defines this bike is the overall visual effect. It takes you right back to the original 1980 G/S in a heartbeat, with that familiar paintscheme accented by the garish red bench seat. It looks set to be a big hit.

The BMW R nineT Urban G/S.
Eye-catching. Powerful. Air-cooled.

Enjoy the confident feel of a boxer with an upright and relaxed riding position, coupled with modern technology. Choose from countless customising options for your own unique ideas. The R nineT Urban G/S makes a clear statement: It pays tribute to the early days of BMW Motorrad's G/S success story. Just one look and it's clear that the R nineT Urban G/S captures the off-road spirit of that era. At the same time, its riding characteristics make it a true member of today's R nineT family. It reflects the way of life of that time: People knew where they wanted to go, and they knew exactly how they would get there.

The source of inspiration: unmistakable.
The design of the R nineT Urban G/S is eye-catching. Distinctive stylistic elements make it a powerful, robust bike that pays tribute to the original G/S design: the 19-inch front wheel, the telescopic fork with the familiar bellows, the headlamp mask with the windscreen and the raised front-wheel cover define the front of the bike. The profile is defined by a pronounced horizontal line. White body elements and the narrow, slightly longer red seat revive the spirit of the legendary R 80 G/S from 1980. The black engine and frame highlight this effect. The new classic round instruments also show that the Urban G/S is part of the R nineT family.

The R nineT Urban G/S also excels on everything from unpaved paths to gravel roads. The optional knubby tyres and spoked wheels, the Enduro foot pegs, the bolted-on heat shield and the steel footbrake lever emphasise the effect, both functionally and visually.

Technology for pure riding fun.
The R nineT Urban G/S is faithful to tradition with its looks, but the bike shows equal respect for the present with its modern technology. It features the proven engine and electrical system of the BMW R nineT. The Urban G/S also meets the current EU-4 emission standard. The powerful air-cooled, two-cylinder boxer engine features a capacity of 1170 ccm and 81 kW (110 bhp) of output for a highly dynamic power delivery, even at low speeds. All for a light and modern riding experience. The standard ABS and optional ASC Automatic Stability Control ensure that you're always safe when you bring your power to the road – or gravel. And there's one last visual reference to the enduro roots of the G/S: the raised exhaust system made of brushed stainless steel.

Upright and majestic.
The balanced ergonomic triangle of the Urban G/S keeps you agile and confident on the road: The slightly higher handlebar, the long seat surface and slightly deeper and wider rear mounted footrests make for a more relaxed and confident riding experience. The standard seat height of the series is 850 mm. Thanks to an optional lower seat, the R nineT Urban G/S offers stability for riders of almost all sizes.

Customizing almost without limits.
Whether you want off-road looks or a retro vibe, the R nineT Urban G/S expresses your lifestyle more than anything else. So when it comes to customising, the possibilities are almost endless, as showcased so well in countless adventures throughout G/S history. The R nineT Urban G/S can be quickly converted into a one-seater thanks to the removable pillion frame. There's also a tailored range of Original BMW Motorrad accessories to choose from. Options include a crash bar, engine guard or protective headlamp grille. The bike also comes with several optional accessories, including spoked wheels, various tanks, ASC (Automatic Stability Control), heated grips or LED turn indicators. But the R nineT Urban G/S is also ideal for installing specially fabricated add-on components such as our new Machined parts. In short: Your individuality is just as unrestricted as your riding pleasure.
