1986 Cagiva Elefant 650

Make Model	Cagiva Elefant 650
Year	1986
Engine	Four stroke, 90° “L”twin cylinder, SOHC, desmodromic 2 valve per cylinder.
Capacity	649 cc / 39.6 cu-in
Bore x Stroke	82 x 61 mm
Cooling System	Air cooled
Compression Ratio	10.0:1
Induction	2x 36mm Dell'Orto carburetors
Ignition	Inductive magnetically triggered
Starting	Electric
Max Power	54 hp / 40 kW @ 8400 rpm
Max Torque	54 Nm / 39.8 lb-ft @ 6200 rpm
Transmission	5 Speed
Final Drive	Chain
Front Suspension	Air adjustable forks 42mm tubes
Front Wheel Travel	220 mm / 8.6 in
Rear Suspension	Single shock absorber. adjustable for spring preload
Front Brakes	Single 260mm disc 4 piston caliper
Rear Brakes	Single 240mm disc 2 piston caliper
Front Tyre	90/90-21
Rear Tyre	130/90-17
Wheelbase	1520 mm / 59.8 in
Seat Height	905 mm / 35.6 in
Dry Weight	191 kg / 421 lbs
Wet Weight	208 kg / 458.6 lbs
Fuel Capacity	17.5 Litres / 4.6 US gal
Consumption Average	38 mpg
Braking 60 - 0 / 100 - 0	- / 41.5 m
Standing ¼ Mile	13.6 sec 152.8 km/h
Top Speed	179 km/h
