CCM FT 710

.

Make Model.

CCM FT 710

Year

2007

Engine

Four stroke, single cylinder, SOHC, 4 valve

Capacity

710 cc / 43.3 cu in
Bore x Stroke

105 x 82 mm.

Compression Ratio

12.2:1

Cooling System

Liquid cooled

Lubrication

Wet sump

Induction

2 x Mikuni BSR32 carburetors

Ignition

Digital CDI

Starting

Electric

Max Power

41 kW / 55 hp

Transmission

5 Speed

Final Drive

Chain

Frame

Tubular steel

Front Suspension

Ø43 mm WP upside down forks

Front Wheel Travel

120 mm / 4.7"

Rear Suspension

Nitron mono-shock, fully adjustable

Rear Wheel Travel

120 mm / 4.7"

Front Brakes

Single Ø320 mm disc, 2-piston caliper

Rear Brakes

Single Ø260 mm disc, 1-piston caliper

Front Tyre

120/70-17

Rear Tyre

150/70-17
Seat Height 830 mm / 32.7 in

Dry Weight

120 kg / 265 lbs

Fuel Capacity

14 L / 3.7 US gal
