Ducati 350XL Pantah

.

Make Model

Ducati 350XL Pantah

Year

1983 - 85

Engine

Four stroke, 90°“L” twin cylinder, Desmo SOHC, belt driven

Capacity

348.9 cc / 21.3 cu in
Bore x Stroke 66 x 51 mm
Compression Ratio 10.4:1

Induction

Dell'Orto PHF30A
Spark Plug Champion L82Y

Ignition

Bosch BTZ electronic

Battery

Yuasa 12V 14Ah

Starting

Electric

Max Power

29.1 kW / 40 hp @ 9600 rpm

Clutch

Wet, multiplate

Transmission

5 Speed

Gear Ratios

1st 2.500 / 2nd 1.714 / 3rd 1.333 / 4th 1.074 / 5th 0.931:1

Final Drive

Chain

Final Drive Ratio

3.143:1 (14/44)

Front Suspension

35 mm Paioli or Marzocchi fork

Rear Suspension

Swingarm, Paioli twin shock, 3-way adjustable

Front Brakes

2 x 260 mm Discs

Rear Brakes

Single 260 mm disc

Front Tyre

3.00-18

Rear Tyre

3.50-18

Dimensions

Length: XL / TL: 2160 mm / 85.0 in. SL: 2150 mm / 84.6 in
Width:   XL / TL:   710 mm / 28.0 in. SL    670 mm / 26.4 in

Wheelbase

1450 mm / 57.1 in

Seat Height

XL / TL: 760 mm / 29.9 in
SL: 740 mm / 29.1 in

Dry Weight

XL / TL: 177 kg / 390 lbs
SL: 176 kg / 389 lbs

Fuel Capacity

18 L / 4.8 US gal / 4.0 Imp gal
Top Speed XL / TL: 170 km/h / 106 mph
SL: 180 km/h / 112 mph
.

The Pantah XL was a simplified version of the fully faired Pantah SL 350, aimed mainly at the Italian market. It was sold in Spain and Greece as well but I am not aware it ever reached the bigger English-speaking markets.

The Italian law offered several advantages to 350 cc bikes: lower VAT purchase tax, lower insurance and road tax, and they could be ridden at 18 years of age, while one had to be 21 to ride a bigger capacity bike. So, most Italian bikes that were born 500 cc were also made in 350 cc versions: the Laverda 8 valve twin, the Guzzi “small block” series and the Ducati parallel twin among them. With the XL Ducati went a little further than just fitting an underbored engine to a big bike: the fixed fairing was removed and a small nose fairing identical to that of the TL model was fitted, some accessories were removed or replaced with cheaper ones to lower the price: there wasn’t the pillion seat cover, the brake discs were solid, the rear shocks were the cheaper Paioli without external reservoir, slightly raised handlebars took the place of the clip-ons… All in all a good bike with a powerful little engine that loved to rev high: max power was claimed to be 38 hp @ 11500 RPM!

But it was more expensive than the Morini 3 1/2 Sport and of the Guzzi Imola, and it wasn’t all that quicker after all. But most of all it was very heavy to be a 350… so sales were never outstanding. Despite being less sophisticated, The Morini was a “proper” 350 and not a bored down 500, so it offered the kind of performance 18 years old wanted (it was nearly 20 kg lighter than the Ducati XL!!). And the Guzzi Imola had that “little Le Mans” aura around it that gave it that extra appeal.

The TL was the first attempt to make a touring bike from the Pantah. Although the Pantah was launched as a “sport touring” bike to be ridden two up, it certainly wasn’t and the need for a more sedate and comfortable bike was felt. So a more comfortable riding position and milder cams were designed for the “Touring L model”. Unfortunately, also a new bodywork was designed. The most positive definition that comes to my mind for this bike’s cosmetics is “perplexing”. The seat and tank are ordinary looking at best, the little nose fairing is something already seen on some Japanese bike of the time. But the long sidepanels that hide the top cylinder are a designer’s bad dream. They hide the vertical cylinder so that motor looks like a horizontal single, Aermacchi style, and the whole bodywork looks heavy and tall. The whole bike reminds of a large semi-bodied scooter. Removing the sidepanels, or hiding them under a proper fairing made things a little better.

It’s a real pity that the TL was so ugly, because it was a good bike. Despite being tuned down from the SL 600, it was fast enough to compete in its class (which included the Guzzi V65, the BMW R60 and the Yamaha XZ 550) and had all the stability and handling virtues of the SL600. The TL was built in 350 and 600 cc versions and was the starting base for the Alazzurra with which it shares more than one can imagine. For example the whole footpegs and pedal compartment is identical.

Alongside the 500, 600, and 650 Pantahs in the early 1980s was a range of 350s specifically produced for the Italian market to accommodate a tax break for motorcycles below 350 cc. The 350 XL was one of Ducati’s parts-bin specialties and essentially a 500 SL with a 600 TL handlebar fairing and higher handlebars. More was sourced from the SL Pantah than the TL, including instruments, instrument panel, and rear-set foot-pegs.

The 350 engine was a downsized 500 SL, with smaller valves (33.5 mm inlet and 30.5 mm exhaust). The Dell’Orto carburetors were smaller (30 mm), and there were new camshafts. The lower end, including the five-speed gearbox and wet cable-operated clutch, was identical to the later 500 SL, and the exhaust system was Silentium. The power was still a healthy 40 horsepower at 9,600 rpm. The 350 XL chassis was also very similar to the 500 SL, with gold FPS wheels, Paioli suspension, and small 05-series Brembo front brake calipers. Attractively styled in red and black, the 350 XL was capable of around 170 km/h. The 350 XL offered here is in excellent original condition, with nice paint and chrome.
