Ducati 916SPS
|
Make Model |
Ducati 916 SPS |
Year |
1998 |
Engine |
Four stroke, 90° “L” twin cylinder, DOHC, desmodromic 4 valve per cylinder, belt driven |
Capacity |
996 cc / 60.8 cu in |
Bore x Stroke | 98 x 66 mm |
Cooling System | Liquid cooled |
Compression Ratio | 11.5:1 |
Induction |
Weber I.A.W. CPU P8 electronic indirect injection |
Spark Plugs | Champion A55V |
Lubrication | Wet sump |
Engine Oil | Synthetic, 15w-50 |
Ignition |
Electronic I.A.W |
Battery | 12V 16Ah |
Starting | Electric |
Max Power |
90.4 kW / 123 hp @ 10500 rpm |
Max Torque | 99 Nm / 73 lb-ft @ 700 rpm |
Clutch |
Dry, multiplate |
Transmission |
6 Speed |
Primary Drive Ratio | 1.84:1 (32/59) |
Gear Ratios | 1st 2.466 / 2nd 1.765 / 3rd 1.350 / 4th 1.091 / 5th 0.958 / 6th 0.857 |
Final Drive Ratio | 2.57:1 (14/36) |
Final Drive | Chain |
Frame | Steel, Trellis frame |
Front Suspension |
43 mm Adjustable Showa GD051 inverted fork |
Front Wheel Travel | 127 mm / 5.0 in |
Rear Suspension |
Öhlins DU 3420 progressive cantilever linkage with adjustable monoshock |
Rear Wheel Travel | 130 mm / 5.1 in |
Front Brakes |
2 x 320 mm Discs, 4 piston calipers |
Rear Brakes |
Single 220 disc, 2 piston caliper |
Front Wheel |
3.50 x 17 |
RearWheel |
5.50 x 17 |
Front Tyre |
120/70 ZR17 |
Rear Tyre |
190/50 ZR17 or 180/55 ZR17 |
Rake | Adjustable 24o - 25o |
Trail | 94 - 100 mm / 3.7 - 3.9 in |
Dimensions |
Length 2030 mm / 80.0 in Width 685 mm / 27.0 in Height 1080 mm / 42.5 in |
Wheelbase | 1410 mm / 56.6 in |
Seat Height | 790 mm / 31.1 in |
Dry Weight |
190 kg / 419 lbs |
Fuel Capacity |
17 Litres / 4.4 US gal / 3.7 Imp gal |
Reserve | 4 L / 1.1 IS gal / 0.9 Imp gal |
Consumption Average |
5.9 L/100 km / 16.9 km/l / 39.8 US mpg / 47.7 Imp mpg |
Braking 60 km/h - 0 |
12.9 m / 42.3 ft |
Braking 100 km/h - 0 |
39.9 m / 131 ft |
Standing ¼ Mile |
10.3 sec |
Top Speed |
269.3 km/h / 167.3 mph |
Road Tests |
Review
First there was the 916. Then the 916 Biposto and 916SP. Now there's the 916SPS, except it's not a 916 at all — it's a 996. Confused? Don't worry — at £18,400 it's a problem none of us mere mortals are likely to face. Simon rides the beastie and fills out his lottery card...
There comes a time in every man's life where he has to hold up his hands and say, 7 was wrong'. It may be the first time you cheated on your girlfriend and got found out. It might be when you had a few too many at a party and decided you were sober enough to drive home. Or howabout when you were 18 and you swapped that 125 you were riding for a nice little Escort coz you thought it was better for pulling the birds, except you failed to realise in 15 years time you'd have missed out on some of the finest thrills money can buy (and you never got a decent shag in the car anyway)?
We've all been there, done that, seen the film, etc.
I had one the other day. I slung a lower limb over a red bike parked in a pitlane and thought to myself, 'Here we go again. Another over-priced, unreliable piece of Italian perversity which requires the riding style and physique of a lemur to get the best from...'
I was not a Ducati fan. Never have been. Used to read the euphoric road tests and dream about them before I got to ride one, but I can still remember the acute sense of disappointment when I tried a Bologna twin (a 900 Superlight, it was) for the first time. Yes, it was torquey, yes it went fast, and yes it handled. But it did none of the things I'd spent a lifetime expecting from a bike. It didn't scream when you revved it. It was too narrow. It vibrated. It sounded like it would explode at any moment. It was awkward to ride slowly, as the lumping pistons clattered the transmission to death. And when you did get going it turned so quickly and easily the kerbs kept rushing up on wrong-line-city.
I sought refuge in Japanese fours and kept Ducatis at a distance after that, despite one Mark Forsyth's continual urging and one Carl Fogarty's continual winning.
And so here I am, in Goodwood pitlane on a Fontiers track day, sat on a Ducati worth 18 grand — a Ducati which, from the crate, finished ninth and set fastest lap in the hands of racer Ian Cobby at the Donington Proddy race four days previously. Not only that, but I'm under the sceptical scrutiny of the bike's owner, Jack Gratton. This is a man who's dealt with enough journos to know what treacherous bastards they are, who races himself and knows a crap rider from a good one, and about whom it would be not be possible to say has more money than sense because ■ the reason he has money in the first place is he used his sense to get it.
Oh well. Press the button, hear the twin lump into life, wobble out onto the track. | Usual Goodwood rules apply — five riders, five laps, then into the pits and join the back of the queue. Don't they know i need about a million laps to get used to riding these things?
First lap is a mild surprise. Either this Ducati feels Japanese, or it's different from every other Duke I've ridden, including the 916 we had at Paul Ricard last month. There's something more natural about the way suspension and the chassis gels... the way it doesn't feel like it's about to be skittered off line by a series of bumps... Next lap is more of the same... what an astounding piece of kit. Massive, dolloping gobs of fuck-off drive from every last rpm of the rev range, a cacophonous bellowing from the mighty Termignonis poking out of my bottom, Dunlop D207s gripping the tarmac like a pair of black, circular magnets, four-pot Brembo calipers grasping at 320mm Brembo discs, and susupension caressing away the bumps like a Thai' masseur who's just seen the size of your wallet.
The rest of the day was spent wallowing in the reflected glory of the 916SPS. There was no way i was going to even get close to its limits on the track — that's what people like Mr Cobby are for. Get on the gas as early and hard as you dare, feel the big motor thumping through the back tyre, and think, 'could have gone harder there...'. Brake like mad for the chicane off the back straight from around 150mph, and think, 'shoulda braked later there...' as you peel in. Sweep through the 130mph right kink with the tarmac eating into your slider like it was made of butter, and think, 'another Wmph, easy, next lap...'. The SPS doesn't just redefine your riding ability it takes the piss.
So what is this thing, where does it fit in the Ducati scheme of things, and why does it cost 18 fatties?
The WSB race motors started life at 916cc — as twins, they can run to lOOOcc. Gradually the competition increased, and to keep ahead of the game Ducati opened up the bores, and each time they did they had to build a number of bikes for sale as homologation models. This is the latest (and last?) version. And it costs £5600 more than a stock 916 because it's got a top-flight Öhlins shock instead of the 916's Showa unit, re-valved Showa forks and the latest fully-floating Brembo discs, calipers and pads with braided hoses. The motor gets two injectors per cylinder (like the SR.. err... confused yet?), bigger valves and downpipes, as well as 4mm on the bores and 10mm more stroke (new, lighter crank). And the cases and barrels are stronger. And the SPS has an upgraded EPROM chip, and you get a set of carbon Termignonis in the crate with the bike.
The result of all this is some 20bhp over the 916, more top end, more midrange and low down, better handling and more stopping power. Of course. It makes the standard 916 feel like a bus.
Certain Italian foibles remain. A blanking bolt in the downpipe (where the factory shove the mixture probe) fell out. Not a problem, apart from the system drawing air in, backfiring, and blowing the packing out of the cans unless you plug it. They all do that, sir. And they all come with self-retracting sidestands, too.
On the road the SPS is as deeply stimulating as it is on the track — more so. It's completely composed over the shittiest tracks, and when you get on fast, open A roads the way it howls along at improbable speeds while you drift around on the seat guiding it this way and t'other... sod the police — you just ride it flat everywhere. They'd never catch you anyway...
And, let's face it, they'd be so impressed with the SPS they'd probably forget to book you. And as for the reactions of that little blonde number in the white Escort at the filling station... doesn't matter what grim fizzog is lurking beneath your helmet — you can afford an SPS, you can afford the plastic surgery to go with it...
Wot a bike.
Source Trevor Franklin
Any corrections or more information on these motorcycles will be kindly appreciated. |
