Harley Davidson XL 883N Iron

.

Make Model.

Harley Davidson XL 883N Iron

Year

2010

Engine

Four stroke, 45° V-Twin, OHV, 2 valves per cylinder.

Capacity

883 cc / 50.8cu in/
Bore x Stroke 76.2 x 96.8 mm
Cooling System Air cooled
Compression Ratio 8.8:1
Exhaust Chrome, staggered, shorty exhaust with dual mufflers
induction Electronic sequential port fuel injection

Ignition

Digital CDI
Starting Electric

Max Torque

73 Nm / 7.44 kgf-m / 53.8 ft/lb @ 3750 rpm

Clutch Multi-plate clutch with diaphragm spring in oil bath

Transmission

5 Speed
Final Drive Belt
Primary Drive Chain, 34/57 ratio
Gear Ratio 1st 10.407 / 2nd 7.436 / 3rd 5.53 / 4th 4.583 / 5th 3.93
Frame Mild steel, tubular frame, circular sections, cast junctions
Swingarm Mild steel, rectangular tube sections, stamped junctions, MIG welded

Front Suspension

39mm Fork
Front Wheel Travel 92 mm / 3.62 in.

Rear Suspension

Coil-over, dual-adjustable preload
Rear Wheel Travel 41 mm / 1.6 in.

Front Brakes

Single ∅300mm disc,  2 x ∅38mm piston calipers

Rear Brakes

Single ∅260mm disc,  2 x ∅38mm piston calipers
Front Wheel Black, 13-spoke cast aluminium
Rear Wheel Black, 13-spoke cast auminium

Front Tyre

100/90B19 57H

Rear Tyre

130/90-16
Rake 31.1°
Trail 117 mm / 4.6 in
Dimensions Length 2179 mm / 85.4 in
Width     821 mm / 32.3 in
Height  1107 mm / 43.5 in
Wheelbase 1519 mm / 59.5 in.
Seat Height Laden    653 mm / 25.7 in
Unladen 683 mm / 26.9 in.
Ground Clearance 120 mm / 4.7 in

Wet Weight

256.3 kg / 565 lbs
Oil Capacity 2.6 Litres / 0.69 US gal

Fuel Capacity

12.5 Litres / 3.3 US gal

With a defiant attitude embracing the pure essence of riding, the new Iron 883 model is the latest Harley-Davidson® Dark Custom™ motorcycle.

Harley-Davidson Sportster motorcycles like the Iron 883 have stood against the grain since their introduction in 1957, when the modern rebel culture was being bred from restless veterans and hot rod pioneers. Sportster motorcycles became the starting point for many legendary choppers of the 1960s, while also getting pumped up for championship dirt racing and dare devil stunt riding in the 1970s.

The Iron 883 model continues that rebellious tradition with responsive handling, smooth clutch effort and durable carbon reinforced drive belt while pushing the styling of motorcycling minimalism to the edge. Decked in black from fender-to-fender, the new Harley-Davidson Iron 883 motorcycle brings the beat of an 883 Evolution® engine backed up by a combo of gritty, old-school garage features like front fork gaiters, drag style handlebar and side-mount license plate holder. A ticket to ride the Iron 883 starts at just $7,899 MSRP, leaving plenty of freedom for customization.

“The Iron 883 defies the plastic conventions of other motorcycles at this price,” said Mark-Hans Richer, Harley-Davidson Chief Marketing Officer. “It’s got old school style, a new school ride and gives the owner a platform for creative customization.”

The black powder-coated 883cc Evolution powertrain with black covers takes the Iron 883 deep into the heart of darkness. With Electronic Sequential Port Fuel Injection (ESPFI) and performance tuning with a broad torque curve, the Iron 883 delivers plenty of power for the city scene. The pipes on the straight cut shorty dual exhaust flow the distinctive Harley-Davidson V-Twin sound.

The black chopped rear fender with its combination stop/turn/tail lights shows more of the 150 mm rear tire and black, 13-spoke cast aluminum wheel, while the front tire also rides on a black wheel. The rest of the Iron 883 gets a darker-suited presence with black front forks and fender supports, fuel tank, oil tank cover, belt guard, drag style handlebar and mid mount foot controls.

A one-piece, solo classic seat with a height of 25.3 inches fits the lone rider, while a passenger seat and a backrest in complementing black finishes can be added as accessories.

As the latest of the Harley-Davidson Dark Custom motorcycles, the Iron 883 is stripped down and ripe for custom creativity. Dark Custom motorcycle riders have the youngest average age for Harley-Davidson buyers. Soul mates of the Iron 883 include the Nightster®, Night Train®, Cross Bones®, Fat Bob® and Street Bob® motorcycles. Check out more on Dark Custom motorcycles at www.harley-davidson.com/darkcustom.

The Iron 883 is available in Black Denim and Brilliant Silver Denim colors.

Rubber-mounted Evolution 883 cc V-Twin black powder-coated engine
Electronic Sequential Port Fuel Injection (ESPFI)
Black fuel tank with unique graphics
Black front forks with gaiters
Black belt guard and front fender supports
Black, 13-spoke cast aluminum wheels, 19-inch front / 16-inch rear
Black low rise drag style handlebar
Black mid-mount foot controls
Black low profile front fender
Black chopped rear fender with combination rear stop/tail/turn lights
Chrome staggered shorty exhaust with dual mufflers
Side-mounted license plate holder
One-piece, solo Sportster classic seat
25.3-inch seat height
Optional Harley-Davidson Smart Security System
Classic 3.3-gallon fuel tank

Source Harley Davidson
