Harley Davidson XLH 1200 Sportster

.

Make Model

Harley Davidson XLH 1200 Sportster

Year

1995 - 98

Engine

Four stroke, 45° V-Twin, OHV, 2 valves per cylinder.

Capacity

1199 cc / 73.2 cub in.
Bore x Stroke 88.8 x 96.8 mm
Cooling System Air cooled,
Compression Ratio 9.0:1

Induction

Single 40mm CV Keihin semi-flat slide

Ignition

Digital CDI
Starting Electric

Max Power

50.4 hp / 37.5 kW @ 6000 rpm

Max Torque

84 Nm / 62 lb-ft  @ 3500 rpm

Transmission

5 Speed
Final Drive Belt
Frame Double cradle steel, box section steel swingarm.

Front Suspension

39mm Telescopic forks, 175mm (6.9in)  wheel travel

Rear Suspension

Dual shocks, preload adjustable, 91mm (3.6in) wheel travel.

Front Brakes

Single 292mm disc 2 piston caliper

Rear Brakes

Single 292mm disc 1 piston caliper

Front Tyre

100/90-19

Rear Tyre

130/90-16

Wet Weight

226.0 kg / 498.2 lbs

Fuel Capacity

12.5 Litres / 3.3 US gal
