Husqvarna Norden 901 Expedition

Make Model	Husqvarna Norden 901 Expedition
Year	2023
Engine	Four stroke, parallel twin cylinder, DOHC, 4 valves per cylinder
Capacity	889 cc / 54.3 cu-in
Bore x Stroke	90.7 x 68.8 mm
Cooling System	Liquid cooled with water/oil heat exchanger
Compression Ratio	13.5:1
Exhaust	Stainless steel primary and secondary silencer
Emission	Euro 5
Lubrication	Pressure lubrication with 2 oil pumps
Induction	DKK Dell’Orto with 46mm throttle body
Engine Management	Bosch EMS with RBW
Traction control	MTC (lean angle sensitive, 3-Mode, disengageable, Explorer mode optional)
Starting	Electric
Max Power	78.3 kW / 105 hp @ 8000 rpm
Max Torque	100 Nm / 73.7 lb-ft @ 6500 rpm
Clutch	Cable operated PASC Slipper clutch
Transmission	6 Speed
Final Drive	Chain 520 X-Ring
Final Drive Ratio	16.45
Primary Drive Ratio	39.75
Frame	Chromium-Molybdenum-Steel frame using the engine as stressed element, powder coated
Subframe	Chromium-Molybdenum-Steel trellis, powder coated
Handlebar	Aluminium, tapered, Ø 28/22 mm
Front Suspension	48mm WP XPLOR-USD, compression, rebound, preload
Front Wheel Travel	240 mm / 9.4 in
Rear Suspension	WP XPLOR-Monoshock, Compression high/low speed, rebound, preload
Rear Wheel Travel	240 mm / 9.4 in
Front Brakes	2x 320mm discs, 4-piston radially mounted calipers
Rear Brakes	Single 260mm disc, 2 piston floating caliper
ABS	Bosch 9.1 ME (incl. Cornering-ABS and Offroad mode, disengageable)
Wheels	Tubeless Aluminium spoked wheels
Front Wheel	2.50 x 21
Rear Wheel	4.50 x 18
Front Tyre	90/90 R 21 Pirelli Scorpion Rally STR
Rear Tyre	150/70 R 18 Pirelli Scorpion Rally STR
Steering Head Angle	64.2°
Rake	25.8°
Trail	106.9 mm / 4.2 in
Triple clamp offset	30 mm / 1.1 in
Wheelbase	1,529 mm ± 15 mm / 60.1 in ± 0.6 in
Seat Height	875 - 895 mm / 34.4 - 35.2 in
Ground Clearance	270 mm / 10.6 in
Dry Weight	211.5 kg / 466.2
Wet Weight	214.5 kg / 472.8 lb without fuel
Fuel Capacity	19 Litres / 5.0 US gal

From a press release issued by Husqvarna Motorcycles:

HUSQVARNA MOTORCYCLES LIFTS THE COVERS OFF AN EXCITING NEW TOURING MACHINE – THE NORDEN 901 EXPEDITION 2023

PREMIUM SUSPENSION AND ESSENTIAL TRAVEL COMPONENTS ALLOW RIDERS TO EXPERIENCE UNRESTRICTED GLOBAL ADVENTURES IN COMPLETE COMFORT

Husqvarna Motorcycles is excited to unveil the Norden 901 Expedition – a new and highly capable touring machine designed to offer endless exploration. Expertly assembled with premium Technical Accessories to improve ease of use, the Norden 901 Expedition comes complete with long travel WP XPLOR suspension to ensure all riders can explore further for longer. The new travel motorcycle is finished with a striking new colour scheme to signify its outstanding capabilities both on and offroad.

Guaranteeing the Norden 901 Expedition excels across the roughest terrain, the new offroad-specific WP XPLOR suspension with 240 mm of travel is fitted to both the front and rear of the motorcycle. This premium, fully adjustable suspension gives riders the opportunity to fine-tune the compression, rebound, and preload settings to create a personalised set-up based on their individual preferences.

Contributing to maximum rider comfort on all long-distance adventures, the Norden 901 Expedition is equipped with many of Husqvarna Motorcycles’ Technical Accessories as standard. For early morning starts and especially beneficial for riders exploring colder climates, the adjustable heated grips and rider’s seat provide instant warmth. Additionally, rider fatigue is reduced considerably with the fitment of a new Touring Windshield. Deflecting wind around the motorcycle, particularly at higher speeds, riders are fully protected and able to discover new worlds in complete comfort.

Turning journeys into expeditions, this convenient new travel motorcycle is built to begin any adventure straight from the showroom thanks to the pre-fitted Side Bag Set. This neat luggage solution integrates perfectly with the bodywork and offers up to 36 litres of storage capacity.

Powered by an 889 cc parallel-twin engine producing 105 hp and 100 Nm of torque, the Norden 901 Expedition offers a broad spread of smooth, controllable power, which is particularly efficient across challenging offroad terrain. Housed inside the steel trellis frame, the versatile engine works together with the chromium-molybdenum chassis to provide exceptional agility, rider feedback, and comfort throughout the longest of riding days.

Completing the build and improving ease-of-maintenance and protection on the longest of riding days, a new centre stand, engine guard, and Connectivity Unit are fitted as standard to enhance every adventure. With the Ride Husqvarna Motorcycles app installed onto a smartphone, and with the device paired to the motorcycle’s Connectivity Unit via Bluetooth, riders will benefit from downloadable maps, Turn-by-Turn+ navigation, Call-In, Call-Out, and view real-time traffic information. Music selection and volume can also be controlled safely while riding using the handlebar-mounted buttons.

Technical highlights:

- WP XPLOR suspension offers longer travel (240 mm) and full adjustability
- Heated grips and rider seat for cold weather comfort
- Touring Windshield for reduced fatigue on extended rides
- Side Bag Set offers convenient storage
- Centre Stand for easier maintenance
- Heavy duty Skid Plate for complete protection of tank and engine
- Connectivity Unit provides Turn-by-Turn+ navigation, Call-In, Call-Out, and music selection from the rider’s smartphone
- Ride Husqvarna Motorcycles app available from Apple AppStore and Google Playstore
- Chromium-molybdenum steel trellis frame with engine as stressed member
- 889 cc parallel-twin engine with 105 hp peak power and 100 Nm of torque
- Four selectable ride modes (Street, Rain, Offroad, Explorer)
- Cutting-edge, switchable cornering ABS with Offroad mode
- Easy Shift function
- Cornering-sensitive traction control allows for nine levels of adjustable rear wheel slip (in Explorer mode)
- Power Assist Slipper Clutch (PASC)
- Tubeless spoked wheels in offroad dimensions and Pirelli Scorpion Rally STR tyres for maximum performance on the street and offroad
- Large capacity 19-litre fuel tank provides an extended range of up to 400 km
