Husqvarna TE 250

Make Model	Husqvarna TE 250
Year	2012
Engine	Four stroke, single cylinder, DOHC, 4 valves
Capacity	249 cc / 15.2 cu-in
Bore x Stroke	76 x 55 mm
Cooling System	Liquid cooled
Compression Ratio	12.9:1
Induction	Electronic Fuel Injection
Ignition	Electric & kick
Starting	Electric
Max Power
Max Torque
Clutch	Wet / Multiplate
Transmission	6 Speed
Final Drive	Chain
Gear Ratio	1st: 28,205 2nd: 22,721 3rd: 18,803 4th: 15,329 5th: 12,974 6th: 11,491
Frame	Steel single tube cradle (round tubes); rear frame in light alloy
Front Suspension	Marzocchi USD telescopic hydraulic fork with advanced axle compression and rebound stroke adjustment Fork leg diameter 50 mm fork
Front Wheel Travel	300 mm / 11.8 in
Rear Suspension	Sachs Progressive Soft Damp type with single hydraulic shock absorber, spring pre-load adjustment. Compression and rebound adjustment (compression stroke - double adjustment)
Rear Wheel Travel	290 mm / 11.4 in
Front Brakes	Single 260mm disc
Rear Brakes	Single 220mm disc
Front Tyre	90/90-21
Rear Tyre	120/80-18
Dimensions	Length 2267 mm / 89.2 in Width 820 mm / 32.2 in Height 1285 mm / 50.5 in
Wheelbase	1485 mm / 58.5 in
Seat Height	963 mm / 38.0 in
Ground Clearance	300 mm / 11.8 in
Dry Weight	108 kg / 238.1 lbs
Fuel Capacity	7.2 Litres / 1.9 US gal

The 2012 Husqvarna TE250 and TE310 both get revised suspension with stiffer 48mm open cartridge forks and rear shock from Kayaba. Exclusive to the U.S. market, the 2012 Husqvarna TE250 has been lowered through new suspension settings, dropping the seat height by two inches to 35.8 inches. Husqvarna says will the lower height will appeal to shorter riders and help distinguish the TE250 from the TE310.

The 2012 Husqvaran TE449 and TE511 also get revised stiffer suspension, as well as a more streamlined wiring harness and new one-piece rear fender. New WP radiators have also been added to improve engine cooling.
