1972 Kawasaki F9 350 Bighorn

Make Model	Kawasaki F9 350 Bighorn
Year	1972 - 75
Engine	Two stroke, single cylinder, rotary valves
Capacity	346 cc / 21 cu-in
Bore x Stroke	80.5 x 68 mm
Cooling System	Air cooled
Compression Ratio	6.8:1
Induction	32mm Mikuni carburetor
Ignition	Battery and coil
Starting	Kick
Max Power	33 hp / 24.2 kW @ 6500 rpm
Max Torque	38 Nm / 28 lb-ft @ 5500
Clutch	Wet, multi-disc
Transmission	5 Speed
Final Drive	Chain
Frame	Double cradle tubular
Front Suspension	Telescopic Hydraulic forks
Rear Suspension	Dual shocks, Swing arm
Front Brakes	152mm Drum
Rear Brakes	152mm Drum
Front Tyre	3.00-21
Rear Tyre	4.00 -18
Wheelbase	1410 mm / 55.5 in
Seat Height	800 mm / 31.5 in
Ground Clearance	216 mm / 8.5 in
Wet Weight	134 kg / 295 lbs
Fuel Capacity	11 Litres / 2.9 US gal

The Kawasaki F9 Bighorn was a 350cc single cylinder, dual-purpose motorcycle manufactured by Kawasaki from 1972 through 1975. The F9 replaced the Kawasaki F5 "Bighorn which was in production from 1970 through 1971.
