kawasaki KLE250

Make Model	Kawasaki KLE 250
Year	1993 -
Engine	Four stroke, parallel twin Cylinder, DOHC, 4 Valves per cylinder
Capacity	248 cc / 15.2 cu-in
Bore x Stroke	62 x 42.2 mm
Cooling System	Liquid cooled
Compression Ratio	12.4:1
Lubrication	Wet sump
Induction	2x 34mm Keihin carburetor
Ignition	CDI
Starting	Electric
Max Power	35 hp / 26 kW @ 1000 rpm
Max Torque	2.4 kgf-m / 17.3 lb-ft @ 10000 rpm
Clutch	Wet, multi disc
Transmission	6 Speed
Final Drive	Chain
Front Suspension	41mm Telescopic forks air assisted
Front Wheel Travel	190 mm / 7.4 in
Rear Suspension	Steal awing arm with preload adjustment
Rear Wheel Travel	190 mm / 7.4 in
Front Brakes	Single 300mm disc 2 piston caliper
Rear Brakes	Single 230mm disc 1 piston caliper
Front Tyre	3.00-19
Rear Tyre	120/80 VR17
Rake	27°
Trail	104 mm / 4.0 in
Wheelbase	1415 mm / 55.7 in
Seat Height	805 mm / 31.5 in
Ground Clearance	270 mm / 10.6 in
Dry Weight	145 kg / 349 lbs
Fuel Capacity	12 Litres / 3.7 US gal

Kawasaki KLE 250
