Kawasaki KLR 250

.

Make Model

Kawasaki KLR 250

Year

1987 - 88

Engine

Four stroke single cylinder, DOHC, 4 valve

Capacity

249 cc / 15.2 cu-in
Bore x Stroke 74 х 58 mm
Cooling System Liquid cooled
Compression Ratio 11.0:1

Induction

Keihin CVK34 carburetor
Main jet.  /  Jet needle. 120  /  N31B

Ignition

CDI
Spark Plug NGK DP9EA-9 or ND X27EP-U9
Starting Kick

Max Power

28 hp / 20.8 kW @ 9000 rpm

Max Torque

2.3 kgf-m / 16.6 lb-ft @ 7500 rpm

Transmission

6 Speed
Final Drive Chain
Gear Ratio 1st 2.000:1  2nd 2.000:1 3rd 1.500:1 4th 1.250:1 5th 1.050:1 6th 0.904:1

Front Suspension

Air-adjustable leading-axle fork
Front Wheel Travel 231 mm / 9.1 in

Rear Suspension

Uni-Trak single shock with adjustable preload and 4-way rebound damping
Rear Wheel Travel 231 mm / 9.1 in

Front Brakes

Single 250mm disc 2 piston caliper

Rear Brakes

Drum

Front Tyre

3.00 - 21

Rear Tyre

4.60 - 17
Rake  28.5°
Trail 117 mm // 4.6 in
Wheelbase 1415mm / 55.71 in
Seat Height 856mm / 33.7 in

Dry Weight

117 kg / 258 lbs

Fuel Capacity

11 Litres / 2.9 US gal
