2017 Kawasaki Versys 650

Make Model	Kawasaki Versys 650
Year	2017
Engine	Four stroke, parallel twin, DOHC, 4 valves per cylinder
Capacity	650 cc / 39.6 cu-in
Bore x Stroke	83 X 60mm
Cooling System	Liquid cooled
Lubrication	Forced lubrication (semi-dry sump)
Compression Ratio	10.6:1
Induction	Fuel injection, 2x 38 mm Keihin
Ignition	Digital CBI
Starting	Electric
Max Power	51 kW / 69 hp @ 8500 rpm
Max Torque	64 Nm / 6.5 kgƒ·m @ 7000 rpm
Clutch	Wet multi-disc, manual
Transmission	6 Speed
Final Drive	Chain
Gear Ratio	1st 2.438 (39/16) 2nd 1.714 (36/21) 3rd 1.333 (32/24) 4th 1.111 (30/27) 5th 0.966 (28/29) 6th 0.852 (23/27)
Final Reduction Ratio	3.067 (46/15)
Frame	Diamond, high-tensile steel
Front Suspension	41 mm inverted telescopic fork with stepless (right-side) adjustable rebound damping and adjustable preload.
Front Wheel Travel	150 mm / 5.9 in
Rear Suspension	Offset laydown single-shock with 13-way adjustable rebound damping and 7-way adjustable preload.
Rear Wheel Travel	145 mm / 5.7 in
Front Brakes	2x 300mm discs 2 piston calipers
Rear Brakes	Single 220mm disc 1 piston caliper
Front Tyre	120/70ZR17
Rear Tyre	160/60ZR17M
Rake	25°
Trail	110 mm / 4.3 in
Dimensions	Length 2165 mm / 85.2 in Width 840 mm / 33.1 in Height 1400 mm / 55.1 in
Wheelbase	1415 mm / 55.7 in
Seat Height	840 mm / 33.1 in
Ground Clearance	170 mm / 6.6 in
Wet Weight	217 kg / 476 lbs
Fuel Capacity	21 Litres / 5.5 US gal

RIDING POSITION AND A COMPACT PARALLEL-TWIN ENGINE RESULTS IN A HIGHLY VERSATILE PACKAGE, OFFERING RIDERS MAXIMUM RIDING EXCITEMENT.

•Compact 649cc parallel-twin engine combines maximum low- and mid-range torque and high-rpm performance for an exhilarating ride
•Slim, upright riding position offers a high level of comfort and nimble handling
•Windscreen with 2 inches of tool-free adjustment adds comfort for highway cruising
•Equipped with a gear position indicator
•GPS mount accessory available

THE RETURN OF THE VERSYS® FAMILY MEANS EVERY ROAD IS AN ADVENTURE
The Kawasaki Versys® family of motorcycles is designed for adventure-style touring.

The award-winning lineup starts with the nimble, easy to maneuver Versys®-X 300 ABS motorcycle. The Versys-X 300 ABS was met with rave reviews when it was introduced to the public earlier this year. It is now returning with new color options, while retaining its adventure capability.

The new colors for the 2018 Versys-X 300 ABS includes Metallic Spark Black/Metallic Flat Raw Graystone and Passion Red/Metallic Flat Raw Graystone.

The Versys® 650 ABS and Versys® 650 LT motorcycles are capable machines designed for fun and comfortable riding. Known for Kawasaki’s torquey 650cc parallel twin engine and lightweight chassis, the Versys 650 LT has smooth handling and responsive feedback. It’s a capable motorcycle that sits nicely in the middleweight category, meeting a variety of riders’ needs. The Versys 650 LT models come standard with hand guards and saddlebags.

The Versys 650 ABS and Versys 650 LT are both returning for 2018 with new color offerings in Metallic Flat Spark Black/Metallic Carbon Gray and Pearl Blizzard White/Metallic Spark Black.

The Versys® 1000 LT rounds out the Versys family of motorcycles, offering the most powerful engine in the lineup, with premium suspension components. ABS is standard on all models along with accessories like saddlebags and hand guards. The Versys 1000 LT has been highly regarded by the media and customers for its immense performance, smooth maneuverability and the ability to eat up miles with ease.

Features

Digital Fuel Injection (KP)
• 38mm Keihin throttle bodies feature dual throttle valves(KP) for optimum performance and rideability. The sub throttles, located behind the main throttle valves, are controlled by the ECU so that the DFI® system has more precise throttle response, similar to a constant-velocity carburetor.
• Precise fuel injection plus exhaust catalyzer significantly reduce emissions.
• Automatic fast idle system makes starting and warm-up easy.

6-Speed Transmission
• Cassette-style transmission puts the transmission shafts and shift drum into a compact layout.
• Positive Neutral Finder, a Kawasaki exclusive user-friendly feature.

Frame
• Rubber front engine mounts help reduce vibration for rider comfort.
• Double-pipe perimeter-frame(KP) is simple and unique and contributes to light handling character. A backbone-style rear subframe keeps the seat narrow for an easy reach to the ground while allowing a thick cushion for comfort.
• Strong rear sub-frame accommodates optional accessory top case for increased touring capacity.
• Double-pipe swingarm matches the frame design and contributes to light, easy handling. Gull-wing shape on the right side allows clearance for the aggressive muffler design.

Triple Petal Design Brake Discs
• Anti-Lock Brake System (ABS) helps assist braking under certain conditions and features a compact Bosch control unit to save space and weight.
• Nissin brake calipers convey a sporty image and contain front and rear brake specific pads; the front providing strong initial bite and the rear offering optimum control and high overall brake force.
• Large rear petal brake disc helps handle heavier loads when accessories are added.
• Front brake calipers have large 27mm pistons for excellent brake feel.
• Petal design offers improved cooling and warp resistance.

CHASSIS
ENGINE

Showa Front Fork
• Derived from high-spec forks on Kawasaki Ninja® sportbikes, the Showa fork separates damping and spring functions into each fork leg. Rebound damping adjustability is in the right fork leg and spring preload in the left leg.
