KTM 1290 Super Adventure S

.

Make Model

KTM 1290 Super Adventure S

Year

2023

Engine

Four stroke, 75°V-twin cylinder, DOHC, 4 valves per cylinder

Capacity

1301 cc / 79.3 cu-in
Bore x Stroke 108 x 71 mm
Cooling System Liquid cooling system, continuous circulation of cooling liquid with water pump
Valve Insp. Interval 18,600 miles
Compression Ratio 13.1:1
Lubrication Forced oil lubrication with 3 oil pumps

Induction

2x Keihin EFI, 52mm throttle bodies
Emission Euro 5
EMS Keihin EMS with RBW and ACC (adaptive cruise control), double ignition, MTC (lean-angle sensitive, 4 modes, disengageable)

Ignition

System contactless, controlled, fully electronic ignition system with digital ignition timing adjustment
Starting Eletric

Max Power

118 kW / 160 hp @ 9000 rpm

Max Torque

138 Nm / 101.7 lb-ft @ 6500 rpm
Clutch PASC™ anti-hopping clutch/ hydraulically operated

Transmission

6-speed
Final Drive Chain 525 X Ring
Frame Tubular space frame made from chrome molybdenum steel, powder-coated

Front Suspension

48 mm WP SAT (semi-active technology) Upside-Down forks
Front Wheel Travel 200 mm / 7.9 in

Rear Suspension

WP SAT (semi-active technology) shock absorber
Rear Wheel Travel 200 mm / 7.9 in

Front Brakes

2 x 320 mm floating disc, Brembo four-piston brake calipers

Rear Brakes

Single 267 mm disc, Brembo two-piston brake caliper
ABS Bosch 10.3ME Combined-ABS (incl. Cornering-ABS and offroad mode)

Front Tyre

120/70-ZR19

Rear Tyre

170/60-ZR17
Steering Head Angle 65.3°
Wheelbase 1580 mm / 62.2 in
Seat Height 849 mm / 33.4 in
Ground Clearance 223 mm / 8.7 in

Dry Weight

220 kg / 485 lbs

Fuel Capacity

23 Litres / 6 US gal
.

From a press release issued by KTM:

WHERE NOW? RACE ANYWHERE WITH THE 2023 KTM 1290 SUPER ADVENTURE S

The benchmark stays but will you go further? The KTM 1290 SUPER ADVENTURE S removed limits and boundaries for any motorcyclist curious to #DARE2ADV. How? The power, versatility, assurance, and technical excellence prompted riders to race into the unknown; safe in the knowledge that what they had underneath them would handle any requirement with a deft touch.

For 2023 KTM has taken the rich base of the KTM 1290 SUPER ADVENTURE S – engineered to conquer mile after mile on all types of terrain – and added a fresh sheen as well as several refinements for the benefit of practical adventuring.

Eyes will be drawn to the two new shades: the glow of the unmissable KTM orange-and-black trim or the more neutral but elegant hue of KTM’s graded gray aesthetic. The orange, that stretches all the way through to the forged aluminum subframe, engineered to offer a lower seat (at 869 mm or 849 mm) superb load-carrying capability and contains a raft of components, is like a badge of honor for hardcore explorers. However, the classy gray spreads across the bodywork; chiseled to prioritize agile handling, front end confidence, comfort, protection and houses the 23-liter three-part tank with superlative fuel range. The tone is as fetching for a swift dash into the office as it would be for a blast across country borders.

Roaming roads everywhere and anywhere with the 2023 KTM 1290 SUPER ADVENTURE S is now a lot easier thanks to augmented navigation software. KTM already made the 7” TFT display a cinch for customization due to the infographics and menu system that gave the rider full control over the RIDE MODES, advanced WP Semi-Active Suspension, ABS settings and Adaptive Cruise Control: the combination of intuitive handlebar switches and access to the technical possibilities of the KTM 1290 SUPER ADVENTURE S was a major calling card for one of the company’s flagship models. For 2023 KTM aimed for more utility. Adventurers can count on extra options with their navigation plotting. The KTMConnect App now boasts Turn-by-Turn+ guidance and waypoints markers while on the go and without having to stop and adjust any mobile device. The same functionality also extends to audio tracks and listing ‘Favorites’ when it comes to phone calls. Hands on the grips not only means gobbling more mileage but safe and more enjoyable interaction with the KTM 1290 SUPER ADVENTURE S.

Let’s remind ourselves why the KTM 1290 SUPER ADVENTURE S is the ultimate high-performance Adventure bike. The V-Twin LC8 rumbles to 160 hp and 138 Nm of torque and the devastating spectrum of power allows the KTM 1290 SUPER ADVENTURE S to glide on cruise, dip through traffic or devore highways with glee. The compact heart of the bike is carefully regulated by one of KTM’s most advanced electronic management architectures: it administers the suspension configuration and reaction, ride height, ABS, RIDE MODES, Tire Pressure Management, Anti-dive and more. The unit fits inside a light 10 kg chrome-molybdenum stainless steel frame honed for handling the short blasts and mountain passes as well as the long haul. The rest of the package befits a premium motorcycle for travelling: the LED lights, reengineered windscreen and adjuster, multi-part saddle, light aluminum side-stand. The list and the specs have already been met with wide acclaim. The KTM 1290 SUPER ADVENTURE S can be elevated even further with optional electronic packs, a Quickshifter+ and WP Suspension Pro amongst other upgrades.

Although a rider might be wishing to reach one, no KTM model is an ‘island’. The KTM 1290 SUPER ADVENTURE S revels in a wide raft of specially made add-ons and accessories in the KTM PowerParts collection. From extra protective parts, aesthetic touches through detailing, performance enhancements or travel items like luggage, racks and bags; the KTM PowerParts are as enticing as it is well equipped.

Highlights of the 2023 KTM 1290 SUPER ADVENTURE S

- Two brand new color schemes with prominent black and orange as well as graded gray choices
- Enhanced navigation potential with Turn-by-Turn+ guidance and more travel options
- Versatile Euro5 V-twin LC8 engine with 160 hp and 138 Nm of torque means a world without limits
- Lightweight ChroMo stainless steel chassis with geometry that accentuates cornering potential & stability
- Sophisticated WP Semi-Active Suspension hardware and software smooths out every route, all the time, any time
- Cutting-edge technology and Bosch 6D sensor to influence bike behavior and ABS settings
- Ergonomics and bodywork emphasizing control but also comfort and confidence, 849 or 869 mm seat height
- A host of optimized travel-minded features: illuminated switches, footpegs, stand, windshield, LED lights and simplistic but advanced dashboard interactivity
- Adaptive Cruise Control as standard
-  Mitas TERRA FORCE-R tires specialized for the KTM 1290 SUPER ADVENTURE S to guarantee the best offering of grip and long-term performance

Snap tight the luggage straps, zip-up the all-weather riding gear, open the GPS, connect the device, close your eyes and dream of the road, trail and the day ahead. Take the 2023 KTM 1290 SUPER ADVENTURE S into the unknown.
