KTM 890 SMT

.

Make Model

KTM 890 SMT

Year

2023

Engine

Four stroke, parallel twin cylinder, DOHC, 4 valve per cylinder

Capacity

889 cc / 54.2 cu-in

Bore x Stroke

90.7 x 68.8 mm

Cooling System

Liquid cooled with water/oil heat exchanger

Compression Ratio

13.5:1

Lubrication

Forced oil lubrication with 2 oil pumps

Induction

DKK Dell’Orto fuel-Injection throttle body 46mm

Emission EURO5

Engine Management

Bosch EMS with RBW

Starting

Electric

Max Power

104 hp / 77 kW @ 8000 rpm

Max Torque

100 Nm / 73 lb-ft @ 650 rpm

Clutch

PASC antihopping clutch, mechanically operated

Traction Control Three mode, disengageable, lean sensitive, optional

Transmission

6 Speed

Final Drive

Chain 520 X-Ring

Frame

Chromium-Molybdenum-Steel frame using the engine as stressed element, powder coated

Front Suspension

43mm WP APEX upside-down forks

Front Wheel Travel

180 mm / 7.1 in

Rear Suspension

WP APEX Monoshock

Rear Wheel Travel

180 mm / 7.1 in

Front Brakes

2 x 320mm discs,  4 piston, radially mounted caliper

Rear Brakes

Single 260mm disc, 1 piston floating caliper

ABS

Bosch 9.1 MP (incl. Cornering ABS and Supermoto mode)

Front Wheel

Cast aluminium wheels 3.50 X 17

Rear Wheel

Cast aluminium wheels 5.50 X 17

Front Tyre

120/70 ZR 17

Rear Tyre

180/55 ZR 17

Rake

24.3°

Steering Head Angle

64.21°

Wheelbase

1502 mm / 59.1 in

Seat Height

860 mm / 33.9 in

Ground Clearance

227 mm / 8.9 in

Dry Weight

194 kg / 427.7 lbs

Fuel Capacity

15.8 Litres / 4.2 US gal

.

From a press release issued by KTM:

Sharper, sleeker, sportier. Take a touch of touring, a pinch of unbeatable tarmac performance and a large vivid spice of Supermoto legacy and serve with speed: KTM is delighted to reintroduce the KTM SMT back to the table. No compromises and no catches. This regeneration of a KTM icon will sweep all highway traffic aside.
Imagine the ultimate Supermoto ‘play weapon’ but also a bike that boasts a number of technical features and additions necessary for extended touring capabilities: you can attack the hill but also know that the bike will take you much further.



Essential information:
KTM 890 SMT back in the spotlight with re-tuned KTM 890 LC8c platform and developed to hit marks at the top of the Supermoto touring segment for power/torque-to-weight ratio.


A street focused chassis, adjustable suspension, premium tires and brakes, and other components elevate this purposeful model between KTM ADVENTURE and KTM STREET product ranges. The perfect foil for hill passes but then the road that lies thereafter.


The 2023 KTM 890 SMT is relaunched with fanfare and pulsating ‘hill climb’ concept in the hands of former AMA Superbike and Supermoto racer Chris Fillmore.

The only way is up. The racing skills of former AMA Superbike and Supermoto ace Chris Fillmore were an apt conduit to display the potential and the limits of the reimagined KTM 890 SMT. The American, and Pikes Peak winner, throttled the Supermoto-tourer along a Sardinian Mountain climb to show petrol heads and the motorcycle industry what they had been missing – and what they had been waiting for.

Fillmore gassed the super-torquey 889cc LC8c parallel twin and counted on 105 hp at 8,000 rpm. The engine is the same platform behind the enviable stats and output of the KTM 890 ADVENTURE R model and variations: with a 20% increase in rotating mass over the KTM 790 platform, providing stability and reassurance through corners, the knock control and 46 mm dual Dell’Orto throttle bodies guaranteeing optimum momentum while the fuel consumption from the 15.8 liter tank is fantastically low at 4.6 liters/100 km. The KTM 890 SMT is just as happy pushed through low revs as pinned in higher gears, in fact Fillmore used the full range of the KTM 790 DUKE’s motor to ace his second Pikes Peak hill climb record in Colorado.


The tank itself plays a forceful role in the ergonomics and has been slimmed and designed specifically for the KTM 890 SMT. The form of the tank slides the rider even further ‘into’ the bike with a wide and comfy contact patch but still compact enough for free and flowing movement (aided by the single piece Supermoto shaped seat at 860 mm height). The aero-optimized smoked windshield is placed just above the double fender concept with a low splash guard on the fork legs. Cruise or attack?

Chassis-wise the KTM 890 SMT has a CroMo steel frame with a tighter geometry that apes the KTM ADVENTUREs. The structure is typically light and superbly agile on the move but also ensures fierce stability the faster a rider pushes. The shock absorber is angled further to reduce the seat height and accommodate the longer swingarm, contributing to a forwardly inclined rider position as well as straight stability.



Feeling the KTM 890 SMT on the go is a prime experience: agile, flighty and responsive. The WP APEX suspension (43 mm open cartridge upside-down forks at 180 mm of travel and same for the shock) is fully adjustable and complements the 17” wheels. The Michelin PowerGP tires supply more than enough stick for the slickest tarmac and have been especially selected for their specs and appropriateness for the KTM 890 SMT’s demands. The state of the art 5” TFT dashboard is made from optically bonded mineral glass and is scratch and glare resistant and fully customizable while divulging the easy-to-use infographic menu system for setup preferences.

The bike can be molded even further. The three standard ride modes (RAIN, STREET, SPORT) can be expanded by an optional TRACK setting that permits the rider to toggle different amounts of throttle modes and traction control through 10 levels. Cornering Motorcycle Traction Control (MTC) is an important safety feature sensitive to the bikes’ pitch and behavior at lean. Try six different handlebar positions with a 30 mm range. The whole show can slide and be wrenched to a halt with potent brakes, with four piston calipers spinning a 320 mm front disc and 260 mm double piston calipers on the rear. Putting this stopping power into action employs Cornering ABS and Supermoto ABS; placing both technically advanced provisions into the mix for an excellent safety profile.

More add-ons include heated grips and the chance to add Motor Slip Regulation (MSR, ideal for better control in low grip situations and for fast downshifts) to the software package. QUICKSHIFTER+ and Cruise Control are optional and ready to go with a simple activation process. Good connectivity with the bike means full access to navigation possibilities, and the advantages of the KTMconnect App include (roadside assistance, owner manuals, digital service booklet for service and maintenance).

It would be very ‘backmarker-ish’ not to mention the looks. The KTM 890 SMT says a lot with its Supermoto tourer style, from the wheels to the sporty graphics. The SMT cuts a sharp profile and will be impossible to miss and harder to outgun on the road. As ever, don’t forget the encompassing collection of KTM PowerParts (accessories and TRACK and TECH Packs) and KTM PowerWear to look the part on the hill, the highway or any hike to KTM 890 SMT happiness.



2023 KTM 890 SMT Highlights

- KTM 890 LC8c reworked for special sport touring emphasis and the next generation of the KTM 890 SMT thanks to 100 Nm of Torque and 105 hp with unbeatable power delivery
- A chassis ideal for the perfect Supermoto-tourer that achieves the desirable pitch between aggression and chilled cruising with a sportier feel
- Frame, engine, wheels, WP APEX suspension all tweaked for lithe performance
- Blast the gradient of any hill climb with Cornering MTC, Cornering ABS and Supermoto ABS all applicable thanks to premium bike behavior functionality. More customization possible with adjustable Suspension and TRACK mode options

- Performance with function: get excited by the tech specs and then revel in the touring aspect of the bike with elements such as the 5” advanced TFT dashboard, Michelin PowerGP tires and optional QUICKSHIFTER+ and Cruise Control among other add-ons
- LED lights, eye-catching styling, 17” wheels and KTM 890 SMT spirit from the first throttle roll.
