MV Agusta Brutale 1000RS

.

Make Model

MV Agusta Brutale 1000RS

Year

2022

Engine

Four stroke, transverse four cylinder, DOHC, radial valves and DLC tappet, 4 valves per cylinder

Capacity

998 cc / 60.9 cu-in

Bore x Stroke

79 x 50.9 mm

Cooling System

Cooling with separated liquid and oil radiators

Compression Ratio

13.4:1

Emission

Euro 5

Engine management system

Integrated ignition - injection system MVICS 2.1 (Motor & Vehicle Integrated Control System) with eight injectors (4 lower fuel injectors by Mikuni + 4 upper fuel injectors by Magneti Marelli with increased fuel flow). Engine control unit Eldor Nemo 2.1, throttle body bore 50 mm diameters full ride by wire Mikuni, pencil-coil with ion-sensing technology, control of detonation and misfire Torque control with four maps - Traction control with 8 levels + off and wheelie control with inertial platform

Starting

Electric

Max Power

208 hp / 153 kW @ 13000 rpm

Max Torque

116.5 Nm / 86 lb-ft @ 11000 rpm

Electronic Quick Shift

MV EAS 3.0 (Electronically Assisted Shift Up & Down)

Clutch

Wet, multi-disc with back torque limiting device and Brembo radial pump/lever assembly

Transmission

Cassette style, 6 speed, constant mesh

Primary Drive

48/82

Final Drive

Chain

Gear Ratio

1st 14/37 2nd 16/33 3rd 18/31 4th 20/30 5th 22/29 6th 21/25

Final Drive Ratio

15/41

Frame

CrMo Steel tubular trellis, Aluminium alloy rear swing arm pivot plates, adjustable swingarm pivot height

Steering damper Öhlins EC with electronic manual and automatic adjustment modes

Front Suspension

50 mm Marzocchi “UPSIDE - DOWN” telescopic hydraulic fork with adjustable rebound-compression damping and external spring preload

Front Wheel Travel

120 mm / 4.72 in

Rear Suspension

Progressive Sachs, single shock absorber with rebound and compression (High speed/Low speed) damping and spring preload adjustment, aluminium alloy single sided swing arm

Rear Wheel Travel

120 mm / 4.72 in

Front Brakes

2x 320mm floating discs and aluminium flange - Brembo radial pump/level assembly

Rear Brakes

Single 220mm disc Brembo PS13 brake pump, Brembo 2 pistons caliper

ABS Continental MK100 with RLM (Rear Wheel Lift-up Mitigation) and with cornering function

Rim Front

Aluminium alloy 3.50 x 17

Rim Rear

Aluminium alloy 6.00 x 17

Front Tyre

120/70 - ZR 17 M/C (58 W)

Rear Tyre

200/55 - ZR 17 M/C (78 W)

Trail

97 mm  / 3.82 in

Dimensions

Length: 2080 mm / 81.89 in
Width:    805 mm / 31.69 in

Wheelbase

1415 mm  / 55.7 in

Seat Height

845 mm  / 33.27 in

Ground Clearance

141 mm  / 5.55 in

Dry Weight

186 kg / 410.06 lbs

Fuel Capacity

16 Litres / 4.23 US gal

Exclusive features Light crankshaft - New combustion chamber Titanium connecting rods - Dashboard TFT 5.5” color display - Cruise control - Bluetooth GPS MV Ride App for navigation mirroring, app- controlled engine, suspension and rider aids setup - Launch Control FLC Front lift control Mobisat tracker
.

From a press release issued By MV Agusta:

NEW BRUTALE 1000 RS

The MV Agusta Brutale 1000 RS takes all the outstanding features of the Brutale 1000 RR to a more accessible level. The Brutale 1000 RS shares the same platform with the Brutale 1000 RR, the most powerful hyper-naked in the world. Both bikes have in common some stand-out features, such as the engine with titanium connecting rods and radial valves, the frame, the single-sided swingarm as well as the Öhlins electronic steering damper while the manually adjustable fork and single shock absorber are RS’s exclusive elements.

The Marzocchi fork and the Sachs single shock absorber, both adjustable, ensure superior performance in fast riding and mean while guaranteeing an excellent comfort when getting around for on-asphalt adventures. The on-board comfort is further enhanced by the the new one-piece saddle featuring a softer padding, not to mention the revised clip-on handlebars – another distinctive trait of the Brutale – which now result raised compared to those of the Brutale RR. The rider can even count on specifically developed footrests, to ensure a rewarding riding position. And it is the unprecedented riding position dedicated to the Brutale 1000 RS that identifies this model as suitable for a wide spectrum of use, which includes, for example, long-distance journeys mixing highway and suburban sections. All this, of course, in the name of performance without however neglecting an eye on comfort.

ENGINE, UNSTOPPABLE IMPROVEMENT

The 4-cylinder engine with radial valves, an exclusive element of the MV Agusta models not only within the segment but throughout the current motorcycle scene, continues its development path through the improvement of components aimed at reducing internal friction.

The new MV Agusta Brutale 1000 RS is powered by an extraordinary engine, which adopts high-end materials. A clear example of this is the titanium connecting rods, a one-of-a-kind solution within the naked segment. Titanium is also used for both the intake and the exhaust valves, thus underlining a technical setting that improves output and boosts torque, worthy of a true superbike. The central timing chain is the latest evolution of what was developed on the 1000 RR. It adopts a further optimised camshaft timing and aimed at making the torque curve at med-low revs even more effective. The use of the DLC (Diamond Like Carbon) coating for the valve control tappets reduces friction and enhances reliability. This goal is achieved also thanks to the use of specific gears for the primary drive; the whole transmission is particularly resistant and reliable, especially in the extreme starts guaranteed by Launch Control. The third generation EAS 3.0 (Electronic Assisted Shift) sees the introduction of an additional sensor, to ensure more precise and smoother shifting. The four-outlet exhaust, an unmistakable MV Agusta stylistic touch, is characterized by the sound-design of the main manifold, which emphasizes the immediately recognizable Brutale tone, in full compliance with the Euro 5 regulations.

This means an extremely precise and effective management of all controls. Thanks to this platform, the FLC (Front Lift Control) traction and wheelie controls protect the safety of the rider, while the system remains “performance-oriented”, offering maximum acceleration in the specific conditions of use. The FLC, in particular, takes the wheelie under control instead of entirely preventing it, with the added benefit to improve performance and riding pleasure.

The new cornering ABS uses the MK100 Continental system, ensuring the best braking control even when cornering, and preventing low side crash. The 5.5” TFT panel, extremely complete and able to communicate with the MV Ride App, allows to set all the bike parameters directly from the smartphone; it also offers many exclusive features, such as the recording and sharing of route itinerary. Thanks to the mirroring function, it is possible to use the RS instrumentation with turn-by-turn navigation. Each function is easily accessible through the joystick positioned on the left block. Moreover, the TPMS tyre pressure monitoring sensor is available as an option.

ELECTRONICS PACKAGE, MORE COMPLETE THAN EVER

State-of-the-art electronics of the new Brutale 1000 RS is the fruit of a relentless development activity. The new IMU detects the motorcycle position in space and in real time, providing the control units with truly reliable data.

Some specific changes to the set-up make it extremely enjoyable to ride, even along winding roads. With the new MV Agusta Brutale 1000 RS versatility meets ease of use. The adoption of mechanical suspensions, namely the Marzocchi fork and the Sachs single shock absorber, represents the optimal formula capable to cover a variety of use. The suspension adjustment range is wide and offers the rider the possibility to effectively customise the setting, according to his own taste and riding situation; ease of adjustment represents another strong point of the components selected for this model.

FRAME, MORE COMFORT AND EFFICIENCY

Radical. Compact. Extremely light. The MV Agusta Brutale 1000 RS chassis is largely shared with the Brutale 1000 RR, and this consequently places this bike at the top of the hypernaked segment.

Some specific changes to the set-up make it extremely enjoyable to ride, even along winding roads. With the new MV Agusta Brutale 1000 RS versatility meets ease of use. The adoption of mechanical suspensions, namely the Marzocchi fork and the Sachs single shock absorber, represents the optimal formula capable to cover a variety of use. The suspension adjustment range is wide and offers the rider the possibility to effectively customise the setting, according to his own taste and riding situation; ease of adjustment represents another strong point of the components selected for this model.

THE MAIN NEW FEATURES OF THE BRUTALE 1000 RS MY 2022

• EURO 5 APPROVED LOW FRICTION ENGINE
• REDESIGNED EXHAUST
• NEW IMU INERTIAL PLATFORM
• ABS CONTINENTAL WITH CORNERING FUNCTION
• NEW FRONT AND REAR SUSPENSION
• NEW RIDER FOOTBOARD SUPPORTS
• REDESIGNED FOOTPEGS
• NEW SEAT

CHASSIS

• MARZOCCHI FRONT FORK AND SACHS REAR SHOCK ABSORBER WITH NEW SETTINGS TO IMPROVE RIDING PRECISION
• OHLINS ELECTRONIC STEERING DAMPER
• RAISED CLIP-ON HANDLEBARS TO IMPROVE RIDING ERGONOMICS
• NEW, MORE COMFORTABLE SINGLE RIDE SEAT WUTH DUAL DENSITY FOAM
• NEW REAR-VIEW MIRRORS TO IMPROVE VISIBILITY
• NEW REAR WHEEL
• NEW FORGED RIDERS FOOTPEG SUPPORTS
• NEW FORGED FOOTPEGS TO IMPROVE GRIP

ADVANTAGES:

COMFORT, STABILITY, AGILITY AND SAFETY, FASTER AND SAFER

ENGINE

• NEW SINTERED VALVE GUIDES AND DLC COATED TAPPETS TO REDUCE FRICTION
• TITANIUM CONNECTING RODS
• 16 RADIAL TITANIUM VALVES
• NEW CAM PROFILES TIMING TO OPTIMISE TORQUE CURVE
• MODIFIED EXHAUST COLLECTOR TO IMPROVE ENGINE TUNING

ADVANTAGES:

BETTER OPERATION AND RELIABILITY, IN FULL COMPLIANCE WITH EURO5 REGULATIONS

ELECTRONICS

• NEW ABS MK100 CONTINENTAL MODULE WITH CORNERING FUNCTION FOR CONSTANT SAFETY EVEN IN CURVES
• NEW INERTIAL PLATFORM
• NEW COLOUR 5.5” TFT DASHBOARD
• MOBISAT TRACKER
• GPS AND BLUETOOTH
• MV RIDE APP
• NAVIGATOR INTEGRATED IN THE DASHBOARD
• FULL LED LIGHTING
• FRONT LIFT CONTROL
• LAUNCH CONTROL
• CRUISE CONTROL
• NEW EAS 3.0 ELECTRONIC GEAR SENSOR

ADVANTAGES:

A BETTER FEELING RIDE. THE ADVANCED ELECTRONICS MAKES RIDING EASIER, MORE INTUITIVE AND SAFER
