Norton V4CR  Café Racer

.

Make Model

Norton V4CR  Café Racer

Year

2023

Engine

Four stroke, 72 ° V-four cylinder, chain-driven cams with idler gear for reduced engine height. Titanium inlet valves.

Capacity

1200 cc / 73.2 cu-in

Bore x Stroke

82 x 56.8 mm

Compression Ratio

13.6:1

Cooling System

Liquid-cooled

Induction

Electronic fuel-injection system, 8-fuel injectors. Full drive-by-wire system independent on front and rear banks of cylinders for ultimate control and feel

Electronic Aids Linked to rider-mode: Lean-angle sensitive Traction-control using six-axis Inertial Measurement Unit (IMU). Front and rear ABS. Wheelie control.

Ignition

Keyless ignition system with electronic steering lock

Starting

Electric

Max Power

185 hp / 136 kW @ 12500 rpm

Max Torque

125 Nm / 92.1 ft-lb @ 9000 rpm

Transmission

Full quickshift system and auto down blipper

Final Drive

Chain

Chassis

Aluminium tubular chassis. Aerospace 5-axis CNC machined outriggers and headstock. Frame is hand TIG welded at Norton HQ and hand-polished to a mirror finish

Swingarm Braced and underslung single-sided billet swingarm with rising rate linkage geometry developed from the TT race bikes

Front Suspension

43mm Öhlins NIX30 system front fork. Fully adjustable

Rear Suspension

Öhlins TTXGP Norton bespoke fully adjustable rear shock

Front Brakes

2 x 330mm floating discs. Radially mounted Brembo monobloc calipers. Brembo discs, and Brembo master cylinder

Rear Brakes

Single 245mm rear disc. Brembo caliper and master-cylinder

Wheels Carbon model: Carbon fibre BSTs
Manx model: Oz racing forged aluminium
Headstock Angle 23.5°

Wheelbase

1435 mm / 56.4 in

Wet Weight 204 kg / 436 lbs

Dry Weight

193 kg / 425.4 lbs

Fuel Capacity

15 Litres / 3.9 US gal

.

We’ve taken everything from the V4SV that we’ve spent years perfecting and placed it in the V4CR, so it’s the same surefooted handling, the same pinpoint power delivery and the same unparalleled attention to detail; we’ve just taken away the barrier between you and the ride. The V4CR is the pure, unmatched joy of the wind in your face and the bugs on your visor.

To us, the V4CR is the ultimate answer to the question of how do you build the world’s greatest café racer? Starting with the V4SV chassis, we’ve stripped back the design, so now you can see even more of the handmade aluminium frame and titanium exhaust. The exposed air intakes at the front, combined with the short body and compact tail unit, gives the V4CR its unique aggressive stance.

But beauty is not enough, so it is also the second motorcycle to be powered by Norton’s own liquid-cooled 1200cc, 72-degree V4 engine, which has been optimised to produce 185bhp at 12,500rpm and 125Nm of torque at 9,000rpm. The combination of a handmade exhaust system and sound of the V4 engine ensures that UK roads reverberate with the iconic snarling of even more Norton engines.

Just like every Norton, each CR is hand built at our factory in Solihull and it inherits all the hallmarks of Norton’s DNA with beauty in its flowing lines, the distinctive forward angle of the engine and the signature hourglass silhouette. It’s also as modern as they come and outfitted with some of the best parts available including adjustable Öhlins front and rear suspension, Brembo brakes, solid aerospace grade aluminium billet-machine yokes, a sophisticated lean-angle sensitive traction-control and three engine modes (wet, road and sport).

As for the finish the Manx Platinum option presents platinum bodywork complemented by carbon panels, a striking orange seat and forged aluminium matte black OZ Piega wheels. The second option, the V4CR Carbon, features exposed carbon fibre bodywork, with a black seat and carbon fibre BST Rapidtek wheels. There’s only one thing we can’t help you with; picking a favourite.

Each component has been elegantly crafted to offer more than just functionality. There’s an attention to detail that takes riders further, adrenaline-fueled at every horizon.

Engineering Elegance

Carbon fibre fuel tank, designed to keep the bike compact.

Tested against the best

Chassis designed and developed in-house, then tested at the world’s most rigorous race track: the Isle of Man TT.

Norton’s own 1200cc v4

1200cc V4, 72-degree, liquid cooled engine – engineered by Norton to produce 185bhp.
