Suzuki Raider R150 / Satria F150 / Belang R150



.

Make Model

Suzuki Raider 150 / Satria F150 / Belang R150

Year

2016 -

Engine

Four stroke, single cylinder, DOHC, 4 valves

Capacity

147.3 cc / 8.99 cu-in
Bore x Stroke 62 x 48.8 mm
Compression Ratio 11.5:1
Cooling System Liquid cooled

Induction

Fuel Injection

Starting

Electric & Kck

Max Power

13.6 kW / 18.2 hp @ 10000 rpm

Max Torque

13.8 Nm / 10.2 lb-ft @ 8500 rpm

Transmission

6 Speed constant mesh
Final Drive Chain
Frame Steel twin-spar diamond

Front Suspension

Conventional telescopic fork

Rear Suspension

Steel swing arm with monoshock

Front Brakes

Single disc, with 2 piston calipers

Rear Brakes

Single disc

Front Tyre

70/90-17

Rear Tyre

80/90-17
Dimensions Length 1960 mm / 77.2 in
Width    675 mm / 26.6 in
Height   980 mm / 38.6 in
Wheelbase 1280 mm / 50.4 in
Seat Height 785 mm / 30.9 in
Ground Clearance 150 mm /  5.9 in

Weight

109 kg / 240 lbs

Fuel Capacity

4.0 Litres / 1.1 US gal
.

The Suzuki Raider 150 or Suzuki Satria 150 and Suzuki Belang R150 in Malaysia uses the 150 cc (9.2 cu in) DOHC four-valve single-cylinder engine based from Suzuki FXR150, with a six-speed transmission. The frame, rear swing arm, rear suspension, seat and front brakes are redesigned from the Suzuki FX125 chassis, making it more aerodynamic.

- Suzuki Satria F150    -  Indonesia and Vietnam
- Suzuki Belang R150  -  Malaysia
- Suzuki Raider R150   -  Thailand, Vietnam and Philippines

The main features are full-length front shock, rear monoshock suspension, six-speed short gear ratio transmission, dual camshaft engine, lightweight chassis construction, alloy cast wheel, large-diameter front disc brake, and a rear disc brake, which is rarely found in underbones.

First Generation (2003)

2003–2008

The first generation Suzuki Raider R150 was assembled in Thailand together with the closely related Raider 125. It has the similarities with the DOHC oil-cooled carbureted engine from FXR150 from Malaysia and also changed the carburettor to a 26 mm, originally 29 mm carburettor size and the power was detuned from 20 PS to 16,5 PS. Suzuki then redesigned the FX125 chassis and made it on an underbone category. The Raider R150 was launched in 2004 in the Philippines, also in Indonesia as Satria F150 replacing 2-stroke Satria 120R, this model was exported from Thailand to other markets in South East Asia. Due to it's popularity, this model was also assembled in Indonesia (CKD) starting from 2007.

2008–2013

In 2008, the Raider got its first facelift and moved the assembling completely to Indonesia. Suzuki Raider 150R got a slight makeover in its design, the most notable change was headlight has changed inspired by that of the GSX-R600/750 superbikes. The Raider 150 was released in 2009 for the Malaysian market as the Suzuki Belang R150 until 2016. The Raider R150 was released in 2013 for the Vietnamese market.

2013–2016

The second facelift arrived in 2013 with new bodywork on the headlights and sharper body style. In 2015, the model got reworked to meet the Euro-3 emission standard. This model also produced in Philippines and as of its present day, and the model are still available along with the new FI model.

Second Generation (2016)

The second generation Raider 150 was introduced in 2016, with totally new design, new digital speedometer, LED headlights, reworked engine with fuel-injection and with liquid-cooled cooling system. This engine also shared with the GSX-R150, albeit with different gear ratios in the transmission, different injectors and different tuning in the ECM. This generation also assembled with CKD kits from Indonesia in Vietnam as Raider 150 and sold together with the fully imported Indonesian built Satria 150.

Source Wikipedia
