1993 - 1997 Suzuki Across

Suzuki Across

Make Model	Suzuki Across
Year	1993 - 97
Engine	Four stroke, transverse four cylinder, DOHC, 4 valves per cyclinder
Capacity	248 cc / 15.1 cu-in
Bore x Stroke	49 x 33 mm
Compression Ratio	12.5:1
Cooling System	Liquid cooled
Ignition	Transistor
Starting	Electric
Max Power	33.6 kW / 45 hp @ 14000 rpm
Max Torque	24 Nm / 2.5 kgf-m / 17.7 lb-ft @ 10500 rpm
Transmission	6 Speed
Final Drive	Chain
Front Suspension	Telescopic forks
Rear Suspension	Full floater
Front Brakes	2 x 300 mm discs, 2 piston calipers
Rear Brakes	Single 240 mm disc
Front Tyre	2.50 -17
Rear Tyre	3.50 -17
Dimensions	Length: 2020 mm / 79.5 in Width: 695 mm / 27.4 in Height: 1120 mm / 44.1 in
Wheelbase	1380 mm / 54.3 in
Seat Height	770 mm / 30.3 in
Dry Weight	159 kg / 350 lbs
Fuel Capacity	16 Litres / 4.2 US gal
Top Speed	180 km/h / 110 mph
