1977 Suzuki GT 500

Make Model	Suzuki GT 500
Year	1977
Engine	Two stroke, parallel twin
Capacity	492 cc / 30 cu in
Bore x Stroke	70 x 64 mm
Compression Ratio	6.6:1
Cooling System	Air cooled
Induction	2 x VM32SS Mikuni carburetors
Ignition	Pointless electronic
Spark Plug	NGK B-7H S
Starting	Kick
Max Power	32.8 kW / 44 hp @ 6000 rpm
Max Torque	53 Nm / 5.4 kgf-m / 39.1 lb-ft @ 5500 rpm
Transmission	5 Speed
Final Drive	Chain
Primary Reduction Ratio	2.50:1
Final Reduction Ratio	4.79:1
Gear Ratios	1st 2.500 / 2nd 1.563 / 3rd 1.158 / 4th 0.955 / 5th 0.870:1
Front Suspension	Telehydraulic fork
Rear Suspension	Dual shocks swinging fork, preload adjustable
Front Brakes	Single disc, single hydraulic piston caliper
Rear Brakes	160mm drum
Front Tyre	3.25-19
Rear Tyre	4.00-18
Rake	39^o
Trail	121 mm . 4.76 in
Dimensions	Length: 2195 mm / 86.4 in Width: 880 mm / 34.6 in Height: 1105 mm / 43.5 in
Wheelbase	1466 mm / 57.7 in
Ground Clearance	160 mm / 6.3 in
Lean Angle	40^o (left and right)
Turning Radius	2.6 m / 8.5 ft
Dry Weight	179 kg / 395 lbs
Fuel Capacity	17 Litres / 4.5 US gal / 3.7 Imp gal
Top Speed (est.)	169 km/h / 105 mph

The Suzuki GT500 replaced the T500 twin in 1975. The new model looked very much like the classic T500, once sensationally fast and well-built machine, but in the mid-seventies already old-fashioned and smoky two-stroker. Its days were outnumbered. Suzuki made a good effort trying to modernize the once very popular model by releasing the GT500 that had a bigger tank, electronic ignition and a front disk brake. Confusingly, the T500 was renamed to GT500 already in 1971 in Japan.
