1972 Suzuki T350

Make Model	Suzuki T 350J Rebel
Year	1972
Engine	Two stroke, parallel two cylinder, piston valve
Capacity	315 cc / 19.2 cu in
Bore x Stroke	61 x 54 mm
Compression Ratio	6.9:1
Cooling System	Air cooled
Lubrication System	Suzuki CCI
Induction	2 x Mikuni VM32 carburetors
Ignition	Battery and coil
Starting	Kick
Battery	12V, 5Ah
Max Power	26.8 kW / 36 hp @ 7000 rpm
Max Torque	38.2 Nm / 3.9 kgf-m / 28.2 lb-ft @ 6000 rpm
Clutch	Wet, multiplate
Transmission	6 Speed, constant mesh
Final Drive	Chain
Gear Ratios	1st 2.33 / 2nd 1.50 / 3rd 1.16 / 4th 0.90 / 5th 0.78 / 6th 0.71
Final Reduction	2.71
Frame	Tubular steel, double cradle
Front Suspension	Telescopic fork, oil damped
Rear Suspension	Twin 3-way adjustable shocks, swingarm
Front Brakes	Drum, internal expanding, double cam
Rear Brakes	Drum, internal expanding
Front Tyre	3.00-18 4PR
Rear Tyre	3.50-18 4PR
Dimensions	Length: 2030 mm / 79.9 in Width: 870 mm / 34.3 in Height: 1130 mm / 44.5 in
Wheelbase	1300 mm / 51.2 in
Ground Clearance	160 mm / 6.3 in
Dry Weight	154 kg / 340 lbs
Oil Capacity	1.2 L / 2.5 US pt / 2.1 Imp pt
Fuel Capacity	15 L / 3.9 US gal / 3.2 Imp gal
Standing ¹/₄ Mile	14.2 sec
Climbing Ability	25^o
Top Speed (claimed)	169 km/h / 105 mph

Suzuki T 350J
