Suzuki TU 250X

.

Make Model

Suzuki TU 250X

Year

2014 - 16

Engine

Four stroke, single cylinder, SOHC, 4 valves

Capacity

249 cc / 15.2 cu-in
Bore x Stroke 72 x 61.2 mm
Cooling System Air/oil-cooled
Lubrication System Wet sump
Compression Ratio 9.2:1

Induction

EFI

Ignition

Electronic ignition (fully transistorized)
Starting Electric

Max Power

15 kW / 20 hp @ 8000 rpm

Max Torque

21 Nm / 2.1 kgf-m / 15.5 lb-ft @ 5500 rpm

Transmission

5 Speed
Final Drive Chain, DID520V, 108 links

Frame

Diamond shaped, steel tube

Front Suspension

Telescopic, hydraulic dampers, coil springs

Rear Suspension

Swinging arm, hydraulic dampers, coil springs

Front Brakes

Single disc

Rear Brakes

Drum

Front Tyre

90/90-18 M/C 51S, tube type

Rear Tyre

110/90-18 M/C 61S, tube type
Dimensions Length 2070 mm / 81.5 in
Width     750 mm / 29.5 in
Height:  1075 mm / 42.3 in
Wheelbase 1375 mm / 54.1 in
Seat Height 770 mm / 30.3 in
Ground Clearance 165 mm / 6.5 in

Wet Weight

149 kg / 326 lbs

Fuel Capacity

12 Litres / 3.2 US gal / 2.6 Imp gal

Top Speed (est.)

120 km/h / 75 mph

The Suzuki TU250X continues towards its tradition of fun. With classic styling in mind, the TU250X includes beautiful spoked wheels, a round headlight, and a sweptback chromed muffler. The TU250X is designed to simply remind everyone an important aspect of riding, to have fun. Light, agile, and smooth performance is what sets the TU250X apart from the competition.

Get a grip on a whole new standard. Striking looks. Comfort. Power. Versatility. Our standards deliver easy ergonomics, modern style, and metro muscle in dynamite packages. Whatever type of riding you prefer, our standards can handle it.

For 2013, the TU250X is available in an all new Metallic Mystic Silver / Glass Sparkle Black combination.

The Suzuki TU250X is perfect for riders seeking a retro looking, user-friendly motorcycle, packed with proven Suzuki reliability and high-quality features.

Delivering a responsive and easy-going ride, the Suzuki TU250X’s 249cc, single-cylinder, fuel-injected, air-oil cooled SOHC engine produces strong low rpm torque, making it ideal for the city rider.

The TU250X’s digitally controlled CDI ignition system provides optimum ignition timing and engine speed, with its five-speed transmission making it ideal for variety of riding conditions.

The TU250X’s generous fuel tank and fuel-efficient engine work together to provide excellent fuel economy and riding range.





An ideal choice for a variety of riders, the TU250X has been designed around a strong diamond-shaped steel frame with a low seat height, compact chassis and upright riding position.

With classic retro styling, the TU250X displays chromed front and rear wheels, headlight case, speedometer cover, tail light housing and exhaust system.

If you want an easy going, classic all-rounder, the TU250X is for you.

Suzuki TU250X Key Features
Suzuki fuel injection provides better fuel efficiency, strong throttle response and easy starting.

249cc, four-stroke, single-cylinder, air-cooled, SOHC engine is equipped with Suzuki's industry-leading fuel injection system.

This fuel-efficient engine produces strong, low-rpm torque, which makes the TU250X a perfect choice for the city rider.

SCEM (Suzuki Composite Electrochemical Material) cylinder allows for improved heat transfer, lightweight and tighter piston clearance.

The TU250X's digitally controlled CDI ignition system provides optimum ignition timing at all engine speeds.

The TU250X's muffler is outfitted with a catalytic converter and O2 feedback system for cleaner exhaust emissions.

Five-speed transmission offers gear ratios that are suitable for a wide variety of riding conditions.

The TU250X is designed around a strong diamond-shaped steel tube frame.

Low seat height and compact chassis.

Front disc brake with dual-piston caliper and rear drum brakes come standard on the TU250X.

The 12 litre fuel tank and fuel-efficient engine work together to provide excellent riding range.

The TU250X is equipped with a full lighting system and easy-to-read instrumentation including trip meter.

Chrome plated front and rear wheels; headlight case; speedometer cover; tail lamp housing; front suspension outer tube; and polished crank side case produce a beautiful, high quality look.

Suzuki TU250X Features and Benefits

Engine Features
249cc, air-cooled four-stroke, single-cylinder, SOHC engine with Suzuki's industry leading fuel injection system is tuned for strong low-end torque well-suited for city riding.

Suzuki Composite Electrochemical Material (SCEM) Plated cylinder for improved durability, weight reduction and superior heat transfer.

Suzuki Dual Throttle Valve (SDTV) fuel injection system, featuring 32mm throttle body, provides superb throttle response, smooth power delivery and reduced emissions.

PAIR (Pulsed-AIR) system injects fresh air into the exhaust port to ignite unburned hydrocarbons, further reducing emissions.

Digital ignition provides optimum ignition timing for increased efficiency and crisp throttle response.

Exhaust system is outfitted with a catalytic converter and oxygen sensor feedback system reducing exhaust emission.

Transmission Features
Smooth-shifting 5-speed transmission has gear ratios suitable for a wide variety of riding conditions.

Chassis Features
Diamond-shaped steel tube frame is lightweight and strong, producing confident and agile handling.

Exhaust system is outfitted with a catalytic converter and oxygen sensor feedback system reducing exhaust emission.

3.2-gallon fuel tank and fuel-efficient engine provide excellent riding range.

Front disc brake with dual-piston caliper and rear drum brakes offer strong braking capabilities.

Additional Features
Contemporary styling thanks to chrome-plated front and rear wheels, headlight case, speedometer cover, tail lamp housing, front suspension outer tube and polished crank side case produce a beautiful, high quality look.

Low 30.3 inch seat height and compact chassis provide confidence-inspiring performance for beginning riders.

Full lighting system and easy-to-read instrumentation include a trip meter.
