Triumph Tiger 800 XR

.

Make Model

Triumph Tiger 800 XR

Year

2019

Engine

Four stroke, transverse three cylinder, DOHC, 4 valve per cylinder.

Capacity

799 cc / 48.7 cub in
Bore x Stroke 74 x 61.9 mm
Cooling System Liquid cooled
Lubrication Wet sump
Oil Capacity 3.7 L / 0.98 US gal / 0.83 Imp gal

Induction

Multipoint sequential electronic fuel injection

Ignition

Digital CDI
Starting Electric
Exhaust Stainless Steel, 3 into 1, high-level stainless steel silencer
Clutch Wet, multi-plate

Max Power

70.8 KW / 95 hp @ 9300 rpm

Max Torque

79 Nm / 8.1 kgf-m / 58 ft.lb @ 7850 rpm

Transmission

6 Speed
Final Drive Chain, O-ring
Frame Tubular steel trellis frame, swingarm: Twin-sided, cast aluminum alloy

Front Suspension

Showa 43mm upside down forks
Front Wheel Travel 180 mm / 7.1 in

Rear Suspension

Showa monoshock with hydraulically adjustable preload
Rear Wheel Travel 170 mm / 6.7 in

Front Brakes

2 x 305 mm floating discs, Nissin 2­piston sliding calipers, Switchable ABS

Rear Brakes

Single 255 mm disc, Nissin single piston sliding caliper, Switchable ABS

Front Wheel

Cast aluminium alloy 10-spoke

Rear Wheel

Cast aluminium alloy 10-spoke

Front Tyre

100/90-19

Rear Tyre

150/70 R17

Rake 24.3°
Trail 95.3 mm / 3.75 in

Dimensions

Length 2215 mm / 87.1in
Width 865 mm / 34.1 in (with handlebars)
Height 1390 mm / 54.7 in (without mirrors)
Wheelbase 1545 mm / 60.8 in
Seat Height 810 mm - 830 mm / 31.8 in- 32.6 in adjustable

Dry Weight

190 kg / 419 lbs
Dry Weight 199 Kg / 438.7 lbs

Wet Weight

213 kg / 469 lbs

Fuel Capacity

19 Litres / 5.0 US gal / 4.2 Imp gal

Delivering a seamless flow of torque across the rev range, the Tiger 800 is as perfectly suited to long distance rides as it is to tackling the tough stuff. The second generation 800cc engine features a ride-by-wire throttle system which provides smoother power delivery, better response, and lower emissions. The result is a 17% improvement in fuel efficiency that coupled with the capacious 19l fuel tank means you can ride longer

Available in two different flavours, the touring focused XR range (XR / XRX / XRX Low / XRT) and the off-road biased XC range, (XC / XCX / XCX Low / XCA) there is a Tiger 800 to suit everyone.

Controls

The Tiger 800 models feature Cruise Control as standard, making long journeys more comfortable and helping fuel efficiency.

Technology

Trip Computer

The LCD screen displays time, ambient temperature, fuel gauge, gear indicator, odometer and journey distance.

The Tiger 800 XRX and XCX models add more functionality with extended information including: journey time, average speed, average fuel consumption, range to empty and instantaneous fuel consumption.

Electronic Riding Modes

Switch from road to off-road to rider programmable modes on the fly – and overcome the weather, the road and whatever nature can throw at you.

The Tiger 800 range offers three different Riding Modes that allow the adjustment of the throttle maps, ABS and TTC to suit different road conditions. Select either Road or Off-Road mode and the throttle maps, ABS, and Triumph Traction Control are automatically set.

RIDER MODE allows you to configure these settings independently to suit your own personal riding style. In Rider Mode, the throttle maps can be switched between Rain, Road, Sport, and Off-Road settings.

Traction Control

Every Tiger 800 features first-in-class standard fitment of Triumph Traction Control that prevents the unexpected spinning of the rear wheel and cuts the engine torque to avoid the loss of lateral grip.

The XCX/XCA and XRX/XRT feature advanced Traction Control with three settings: 1. ROAD: optimised for road use, allowing minimal rear wheel slip 2. OFF ROAD: allows increased rear wheel slip 3. OFF: disables the traction control setting

Controls

The Tiger 800 models feature Cruise Control as standard, making long journeys more comfortable and helping fuel efficiency.

Engine

Triple Engine

Delivering a seamless flow of torque across the rev range, the Tiger 800 is as perfectly suited to long-distance rides as it is to tackling the tough stuff. The second generation 800cc engine features a ride-by-wire throttle system which provides smoother power delivery, better response and lower emissions.

Fuel Efficiency

The new Tiger 800 has a 17% improvement in fuel efficiency that, coupled with the capacious 19L fuel tank, means you can ride longer.

Gear Box

The gearbox selector mechanism is derived directly from the class leading Daytona, for quicker smoother shifts.

Accessories

LED Fog Lights

High performance dual Fog Lamp Kit featuring high power Philips Altilin LEDs, drilled and brushed marine grade aluminium shields and an integrated tubular mounting rail. Fully waterproof illuminated push button for ease of use in the worst of conditions.

Low Seat

Low Comfort Rider Seat unit to offer optimum comfort and style. Approximately 20mm lower compared to the standard part, features twin fabric cover, contrasting stitch detail and Triumph branding to ensure it looks as good as it feels.

Panniers

These fully weatherproof panniers are made from a 1.5mm thick aluminium structure, with the enhanced protection of polymer corner reinforcements. Each Pannier has a capacity of 37 litres, attaching to bespoke mounting frames, using a quick release mechanism.

Hand guards

Manufactured from durable moulded nylon, Triumph Hand Guards now have improved wind resistance and finger clearance. Tested in a wind tunnel for optimum performance.

Handlebar Risers

Offering a height adjustment distance of 30mm, these Handlebar Risers replace original parts to ensure improved ergonomics for taller riders

Heated Grips

Designed specifically for the Tiger 800, these internally wired Heated Grips feature dual temperature heat settings, selectable through bar mounted dual colour push button controls.

Find Your Tiger

THE XR RANGE The new Tiger 800 XR models offer a dynamic adventure bike range that truly deliver on the road. Powered by a 95PS 800cc triple, with the first in class inclusion of switchable ABS and Triumph Traction Control, the 800 XR range offers an agile, purposeful option for those seeking a perfect day to day riding tool, or a long distance adventure companion. With cast wheels, 19-inch at the front, and a chassis tuned for outstanding road manners, the XR models are highly capable of delivering riding fun and long distance comfort.

THE XC RANGE The new Tiger 800 XC models are designed to be perfect off-road bikes offering those with serious off-road intent the perfect all-purpose machines capable of going the distance. The responsive chassis and torque-laden engine is matched to the perfect blend of technology, equipment and style, resulting in a bike that can tackle the most arduous of journeys with ease. With premium WP suspension as standard, 21” spoked wheel at the front and 17” at the rear, and increased rider focussed technology including the standard fitment of traction control and switchable ABS, the Tiger 800 XC is no ordinary adventure bike.
