Triumph America LT

.

Make Model

Triumph America LT

Year

2015 - 16

Engine

Four stroke, parallel twin cylinder, DOHC, 4 valves per cylinder, 360° firing interval

Capacity

865 cc / 52.8 cub in.
Bore x Stroke 90 x 68 mm
Cooling System Air-cooled
Compression Ratio 9.2:1

Induction

Multipoint Sequential Fuel injection with SAI
Lubrication Wet sump
Engine Oil Synthetic, 15W/50
Oil Capacity 4.5 L / 1.2 US gal / 1.0 Imp gal
Exhaust Stainless steel twin-walled headers, twin chromed silencers

Induction

Twin carburettors, with throttle position sensor and electric carburettor heaters

Ignition

Digital

Starting

Electric

Max Power

45.5 kW / 61 hp @ 6800 rpm

Max Torque

72 Nm / 7.34 kgf-m / 53.1 ft-lb @ 3300 rpm
Clutch Wet multi plate

Transmission

5 Speed
Final Drive Chain, X-ring
Frame Tubular steel cradle, swing arm: twin-sided, tubular steel

Front Suspension

41mm Kayaba telescopic forks, polished stainless steel shrouds
Front Wheel Travel 120 mm / 4.7 in

Rear Suspension

Kayaba chrome spring twin shocks with adjustable preload
Rear Wheel Travel 96 mm / 3.8 in

Front Brakes

Single 310 mm disc, Nissin 2 piston floating caliper

Rear Brakes

Single 285 mm disc, Nissin 2 piston floating caliper
Wheels Front Cast aluminum alloy, 12 spoke, 16 x 3.0 inch
Wheels Rear Cast aluminum alloy, 12 spoke, 15 x 4.0 inch

Front Tyre

130/90 - 16

Rear Tyre

170/80 B15
Rake 33.3°
Trail 143 mm / 5.6 in
Dimensions Length 2387 mm / 94.0 in
Width     920 mm / 36.2 in (at handlebars)
Height  1480 mm / 58.3 in (with screen)
Wheelbase 1610 mm / 63.4 in
Seat Height 690 mm / 27.2 in

Wet Weight

270 kg / 595 lbs

Fuel Capacity

19.3 Litres / 5.1 US gal / 4.2 Imp gal

From a cross-town hop to an intercontinental tour, the America LT will take you there in style. Based on the engine, chassis and legendary styling of our America, the LT adds a layer of touring capability and an enviable range of factory fitted extras designed to make those longer distances a breeze. All the while maintaining the traditional deep chrome and polished detailing demanded of a classic cruiser, of course.

The America LT adds a layer of touring capability to the America via a range of carefully selected factory fitted extras designed to make long distance riding even more comfortable and convenient.

Comfortable all day riding position with a sumptuous, scalloped seat, wide footboards, pulled back handlebars, and excellent wind protection.

  • Detachable high level tour wind shield for weather protection
  • Stylish showerproof leather panniers
  • Pillion back rest / Sissy Bar

Styling

Striking machined fins pick out the distinctive parallel twin shape, while chrome engine covers are offset against jet-black barrels and crankcases. A pair of wide, dramatically splayed exhaust pipes dominate the LT’s front three-quarter profile with their classic ‘header-run’ following a straight line from the throttle bodies through to the headers. Our parallel twin heritage for all to see and admire.

Chassis

Swept-back classic styling, characterised by details such as the dramatic slab top yoke, centre-mounted white-faced speedo, large single headlight, chrome tank console housing and filler cap, and hand-painted tank and mudguard coachlines.

Performance

Built to be ridden, not just to look good. The America’s 865cc parallel-twin puts out a healthy 61PS with strong torque at low revs, peaking at 72Nm at just 3300rpm. Ideal for urban cruising at low revs but with enough muscle for serious long distances at motorway speeds, even with a passenger or luggage on board.

This vertical twin is a true original. Drawing on our heritage from fifties and sixties parallel twins and coupling that with modern technology and build standards, the engine in the America has a laid-back riding character that’s unique to the cruiser world.

Configuration

Straight away people notice the America’s unmistakably British style. Its pair of cylinders stand upright and proud and make a powerful statement. And, being air-cooled there’s no radiator to spoil the view.

Suspension

With forks raked out at a shallow angle and feature polished shrouding and silver legs that match the chrome springs and covers of the laid-down, twin rear shocks. The America’s suspension works hard to provide laid-back comfort and road feedback in true cruiser style.
Handling

Long, low and stable like a cruiser should be.

Everything about the America’s chassis is focussed on balance and we’ve matched each component carefully to maintain that steady, intuitive feel.

As a result, it’s agile enough for an exciting ride when the road gets interesting and is more capable through the corners than most of its rivals.

It’s so well-balanced that it is ideal for inexperienced riders as well as a satisfying cruise for those with a lot of miles behind them.

Brakes

Never too sharp or intimidating, braking is looked after by single discs front and rear to provide plenty of stopping force, whilst maintaining the overall balance of the chassis so every moment of your ride is confident and controlled.

Wheels and Tyres

The cast aluminium wheels are small in diameter. 16 and 15 inches front and rear and fitted with chunky, deep sidewall tyres for a classic cruiser look and a more comfortable cushioned ride.

Seat Height

A seat height of just 690mm makes the America easy to control when gliding through traffic or parking. In fact, the set-up suits many riders that find other bikes too tall. Whatever your height though, easy positioning of the bars, seat and footrests means you’ll quickly find your most relaxed and comfortable cruising posture.

Riding Position

As a pure unadulterated cruiser, your riding position should be upright, laid back and spacious. But never at the expense of comfort and sheer riding pleasure. So the America’s bars hang high and wide but are also pulled back so that the controls are closer to you. And we’ve set the footrests far enough forward for comfort, without being too much of a stretch. Putting you in firm, confident control of your bike during busy urban riding or long-distance travel.

Footboards

High-quality aluminium foot-boards and removable skid plates come with a classic heel/toe gear shift, positioning the rider’s feet for maximum comfort and control.

Saddlebags

At the back, the America LT’s generous leather panniers are showerproof and come with metal buckles over durable, easy-to-use plastic clips.

Windshield

The tall wind-shield deflects the worst of the weather and is easily detachable (via a pair of spring-loaded levers at each side of the screen) to achieve a completely alternative look.

Back Rest - Sissy Bar

We added a pillion backrest to add all day comfort for your passenger too.
