Yamaha IT 125

.

Make Model

Yamaha IT 125

Year

1980 -

Engine

Two stroke, single cylinder, reed-valve inducted

Capacity

123 cc / 7.51 cu-in
Bore x Stroke 56 x 50 mm
Cooling System Air cooled
Compression Ratio 8.1:1

Induction

30 mm Mikuni carburetor

Ignition

CDI
Starting Kick

Max Power

17.36 hp / 12.7 kW @ 8500 rpm

Max Torque

14.5 Nm / 10.73 lb-ft @ 8500 rpm
Clutch Wet, multi-disc

Transmission

6 Speed
Final Drive Chain
Frame Single-downtube, full cradle, chromoly frame, tubular section, chomoly swingarm

Front Suspension

Telescopic forks
Front Wheel Travel 180 mm / 7.0 in

Rear Suspension

Monoshock
Rear Wheel Travel 200 mm / 7.8 in

Front Brakes

Drum

Rear Brakes

Drum

Front Tyre

3.00 x 21

Rear Tyre

4.10 x 18
Wheelbase 1365 mm / 53.7 in
Seat Height 846 mm / 33.3 in
Ground Clearance 284 mm / 11.2 in

Wet Weight

99 kg / 218 lbs

Fuel Capacity

8.5 Litres / 2.2 US gal
.
