Yamaha IT 250

.

Make Model

Yamaha IT 250

Year

1978 -

Engine

Two stroke, single cylinder, read valve

Capacity

246 cc / 15.07 cu-in
Bore x Stroke 70 x 64 mm
Cooling System Air cooled
Compression Ratio 7.8:1

Induction

36mm Mikuni carburetor

Ignition

CDI
Starting Kick

Max Power

26.1 hp / 19 kW @ 7500 rpm

Max Torque

25 Nm / 18.5 lb-ft @ 7500 rpm
Clutch Wet, multi-plate

Transmission

6 Speed
Final Drive Chain
Frame Double downtube, full-cradle

Front Suspension

Telescopic forks

Rear Suspension

Swing arm with monoshock

Front Brakes

Drum

Rear Brakes

Drum

Front Tyre

3.00 x 21

Rear Tyre

4.50 x 18
Wheelbase 1430 mm / 56.3 in
Seat Height 889 mm / 35 in
Ground Clearance 241.3 mm / 9.5 in

Wet Weight

124 kg / 275 lbs

Fuel Capacity

12 Litres / 3.2 US gal
.
