1972 Yamaha TX 750

Make Model	Yamaha TX 750
Year	1972
Engine	Four stroke, parallel twin cylinders, SOHC 2 valve per cylinder
Capacity	743 cc / 45.3 cu-in
Bore x Stroke	80 x 74 mm
Cooling System	Air cooled
Compression Ratio	8.8:1
Lubrication	Forced dry sump
Induction	Carburetor
Ignition
Starting	Electric & Kick
Max Power	63 hp / 45.9 kW @ 6100 rpm
Max Torque	7 kgf-m / 50.6 lb-ft @ 6000 rpm
Transmission	5 Speed
Final Drive	Chain
Front Suspension	Telescopic forks
Rear Suspension	Dual shock
Front Brakes	Single or dual 300mm disc 2 piston calipers (In Japan, the United States, and other markets the bike had a single disc, although the lugs needed to mount a second disc were in place. )
Rear Brakes	180mm Drum
Front Tyre	3.50-19
Rear Tyre	4.00-18
Rake	27°
Trail	99 mm / 3.9 in
Dimensions	Length 2205 mm / 86.8 in Width 909 mm / 35.8 in Height 1165 mm / 45.9 in
Wheelbase	1455 mm / 57.3 in
Seat Height	810 mm / 32 in
Ground Clearance	160 mm / 6.3 in
Wet Weight	235 kg / 518 lbs
Fuel Capacity	14 Litres / 3.7 US gal
