1977 Yamaha XS 750 Touring

Make Model	Yamaha XS 750 Touring
Year	1977
Engine	Four stroke, transverse three cylinder, DOHC, 2 valves per cylinder
Capacity	747 cc / 45.6 cu-in
Bore x Stroke	68 x 68.6 mm
Compression Ratio	8.5:1
Cooling System	Air cooled
Induction	3 x 34mm Mikuni carburetors
Ignition	Battery and coil
Starting	Electric
Max Power	47.7 kW / 64 hp @ 7500 rpm
Transmission	5 Speed
Final Drive	Shaft
Front Suspension	Telescopic forks, 36 mm
Rear Suspension	Dual shocks swing arm, preload adjustable
Front Brakes	2 x 267mm Discs
Rear Brakes	Single 267mm disc
Front Tyre	3.25-19
Rear Tyre	4.00-18
Dry Weight	231 kg / 470 lbs
Wet Weight	249 kg / 550 lbs
Fuel Capacity	15 Litres / 4.0 US gal
Oil Capacity	2.8 Litres / 6.0 US pts
Consumption Average	5.5 L/100 km / 18.2 km/l / 42.9 US mpg
Braking 100 km/h - 0	42 m / 138 ft
Standing Â¼ Mile	14.1 sec / 146.6 km/h / 91.1 mph
Top Speed	171 km/h / 106 mph
