Yamaha XT 350

.

ake Model

Yamaha XT350

Year

1986

Engine

Four stroke, single cylinder,  DOHC, 4 valve, YDIS

Capacity

346 cc /
Bore x Stroke 86 x 59.6 mm
Cooling System Air cooled
Compression Ratio 9.0:1

Induction

Y24PV carburetor

Ignition

CDI
Starting Kick

Max Power

31.5 hp / 22.8 kW @ 7500 rpm

Max Torque

29.5 Nm / 21.7 ft-lb @ 7000 rpm

Transmission  /  Drive

6 Speed
Final Drive Chain

Front Suspension

Telescopic forks

Rear Suspension

Mono-cross

Front Brakes

Single disc

Rear Brakes

Drum

Front Tyre

3.00- 21

Rear Tyre

4.00-18
Dimensions Length  2210 mm / 87.0 in
Height  1210 mm / 47.6 in
Width   865 mm / 34.0 in
Wheelbase 1420 mm / 55.9 in
Seat Height 855 mm / 33.6 in
Ground Clearance 275 mm / 10.8 in

Dry Weight

120 kg / 264.5 in

Fuel Capacity

12 Litres / 3.1 US gal
