Yamaha YDS-1

.



Make Model

Yamaha YDS-1

Year

1959-61

Engine

Two stroke, piston-port, parallel twin

Capacity

247 cc / 15.0 cu-in
Bore x Stroke 54 x 54 mm
Cooling System Air-cooled
Compression Ratio

Induction

Single carburetor

Starting

Kick

Max Power

18 hp @ 7500 rpm

Max Torque

5.2 kgf-m @ 6000 rpm

Transmission

5 Speed
Final Drive Chain

Front Suspension

Telescopic forks

Rear Suspension

Swing arm

Front Brakes

Drum

Rear Brakes

Drum

Front Tyre

3.00 -18

Rear Tyre

3.00 -18

Wet Weight

138 kg / 309 lbs

Fuel Capacity

The YDS-1 mounts a tuned-up version of the YD-1 motor in a double-cradle frame (the earlier version was built on a pressed-steel spine). The YDS-1 establishes the pattern for the next 20 years of sporty Yamaha two-stroke Twins.
